NOTES ON MAINTENANCE
Checking the brake linings
CAUTION
The minimum lining thickness must be
maintained.
NOTE
For your own safety, we recommend having
activities to the brake system carried out by
a Sachs deal er.
Front wheel brake
- Remove the protective cap (1) at the
brake calliper.
- Visually inspect the sight glass (2) at the
brake calliper.
- Check the thickness of the brake lining.
Minimum thickness: A = 2.0 mm
- If the lining thickness is below the mini-
mum, have the brake lining (2) replaced
by a Sachs dealer.
Checking the disc brake
- Visually inspect the disc brake (3).
- Check the thickness of the disc brake.
Minimum thickness: B = 3.0 mm
- If the disc thickness is below the mini-
mum, have the disc brake (3) replaced
by a Sachs dealer.
