6 DESCRIPTION OF CONTROLS
6.1 Controls
The appliance is equipped with the following controls:
• Power button
• Control panel
6.1.1 Power button
When the machine is connected to the mains and the
all-pole switch is set to "I", the following happens when
operating the power button:
• Power button set to “0”, the control panel is off.
• Power button set to “I”, the control panel is on.
The fact that the power
button is set to “0” does
not represent a guarantee
that the machine is not
powered.
When performing any kind
of cleaning or maintenance
operations inside the
machine, disconnect it
from the mains and set the
all-pole switch to “0”.
6.1.2 Control panel
The control panel is sensitive to the touch, i.e. it combines
the functions of a display with those of a keypad.
The display areas which are sensitive to the touch change
according to the current machine phase, e.g. standard
operation or maintenance.
