In the following table, for the example, the temperature and the corresponding voltage current and
power parameter settings are reported for activation and conditioning of the most popular SAES
getter pumps, like the CapaciTorr and the NEXTorr families, without jacket.
Activation
Mode
Conditioning
Mode
NAME
Vmax
Vmax
CT D100 9 V 3.5 V
CT D200 12 V 4 V
CT D400-2 16 V 7 V
CT D50 8 V 3 V
CT HV 200 35 11.3 V 3.3 V
CT HV 200 63 12.6 V 3.7 V
CT Z100 8 V 4 V
CT Z200 11 V 5 V
CT Z400 body 15 V 5 V
CT Z400 nude 18 V 7 V
GP50-2F 25 V 11 V
NXT D100-5 9 V 4.5 V
NXT D200-5 12.5 V 6 V
NXT D300-5 20 V 8 V
NXT D500-5 28 V 10 V
NXT HV 100 9 V 2.8 V
NXT HV 200 12 V 3.5 V
NXT HV 300 30 V 8 V
NXT Z100 9 V 4 V
NXT Z200 12 V 5 V
NXT Z300 24 V 9 V
NXT D500-StarCell 28 V 10 V
ATTENTION: SAES Getters is not responsible for damages due to improper use of the
power supply
