SAES NEG Power mini - Appendix A: Supply Cables

M.HIST.0138.23 R1 Page 25 of 28 October, 06
th
2020
APPENDIX A: Supply cables
GP 50-2F
For the GP 50 pump and pumps not equipped with an electrical connector use the output supply
cable supply shown in figure:
Brown
Blue
Yellow/Green
21
gnd
3 5
Yellow/Green
Blue
Brown
TO NEG PUMP CONTROLLER
REAR VIEW OF CONNECTOR
TO GETTER PUMP
CapaciTorr D400-2, CapaciTorr Z400
CapaciTorr HV200 35, CapaciTorr HV200 63
For these pumps which are equipped with a dedicated electrical connector, use the output supply
cable shown in figure:
Yellow/green
Brown
A
D
C
B
Blue
e
21
gnd
3
5
Yellow/Green
Blue
Brown
TO NEG PUMP CONTROLLER
REAR VIEW OF CONNECTOR
TO GETTER PUMP
