USER MANUAL - SIP POWER ION PUMP CONTROLLER
M.HIST.0109.23 Rev.1 Page 10 of 62
2.7. The front panel of the unit with LEDs and RS485 interface
12. “ON LINE” Status LED: if it is on it means that the instrument is on
13. “HV OUTPUT ACTIVE” Status LED is on when power is issued to the pump
14. RS485 connector
15. ON/OFF instrument power switch
2.8. Supplied accessories
The following accessories are provided with SIP POWER (version 3B0506):
- Power supply 220V – 24 Vdc with shuko wall plug cable
- DB15 plug with PIN to bypass Interlock and Safety connections
- Saes Group USB stick with
o User manual
o SIP power manager: software for remote control via LAN
o SIP power controller: software for remote control of one unit via RS485
o SAES product brochures
12
14
15
13
