USER MANUAL - SIP POWER ION PUMP CONTROLLER
M.HIST.0109.23 Rev.1 Page 8 of 62
2.5. The front panel of the unit
1. Alphanumeric display
2. START/STOP button to switch on/off the output
3. A/V/W button to change the parameter shown on display; current, voltage or power alternately
4. Torr/Pa/mb button to change the unit of pressure between Torr, Pascal or mbar respectively
5. ON/OFF instrument power switch
2.6. The rear panel of the unit
3
4
1
5
2
6
11
10
7
8
9
