USER MANUAL - SIP POWER ION PUMP CONTROLLER
M.HIST.0109.23 Rev.1 Page 31 of 62
0x3002 1 R bit-mask STATUS power supply status
0x3003 1 R bit-mask SW_STATUS status of SW1, SW2 and SW3 output
0x3004 2 R Uptime UPTIME time elapsed since last start [s]
0x3006 1 R unsigned integer VIN current voltage input [dV]
0x3007 1 R unsigned integer VOUT current voltage output [V]
0x3008 2 R unsigned integer IOUT current output current [nA]
0x4000 1 R/W unsigned integer VOUT_SETPOINT output voltage set point [V]
0x4001 2 R/W unsigned integer VOUT_RAMP_INTV output voltage ramping interval [ms]
0x4003 1 R/W bit-mask SW_MODE switches modes for SW1, SW2 and SW3
0x4004 2 R/W unsigned integer SW1_THR switch SW1 threshold [nA]
0x4006 2 R/W unsigned integer SW2_THR_MIN switch SW2 min threshold (or threshold in
simple mode) [nA]
0x4008 2 R/W unsigned integer SW2_THR_MAX switch SW2 max threshold (unused in
simple mode) [nA]
0x400a 2 R/W unsigned integer SW3_THR_MIN switch SW3 min threshold (or threshold in
simple mode) [nA]
0x400c 2 R/W unsigned integer SW3_THR_MAX switch SW3 max threshold (unused in
simple mode) [nA]
0x400e 1 R/W unsigned integer CONV_RATE conversion rate [A/Torr]
0x5000 2 R/W IP address IP_ADDR IP address (only for Ethernet model)
0x5002 1 R/W IP net-mask IP_NETMASK IP network mask (only for Ethernet
model)
0x5003 3 R Ethernet MAC
address
MAC_ADDR Ethernet interface mac address (only for
Ethernet model)
0x5006 2 R/W unsigned integer KEEPALIVE keepalive time interval
0x6000 1 W unsigned integer ENABLE_CMD enable command (stop:0x0000
start:0x0001 restart:0x0002)
0x6001 1 W unsigned integer ALARM_CLEAR alarm latches clear command
0x7000 1 W unsigned integer CRITICAL_STEP1 critical step1 bypass command
0x7001 1 W unsigned integer CRITICAL_STEP1 critical step2 bypass command
0x8000 1 W unsigned integer MODBUS_ID power supply Modbus ID
0x8001 1 W unsigned integer LIFE_TIME_RESET total working hours reset
