Networking Data Registers
Following registers are useful to set and retrieve networking settings. These registers are available
only if ETHERNET flag is set in CARD_TYPE register.
IP_ADDR – 0x5000 – IP address
Bit 31 30 29 28 27 26 25 24
IP_ADDR[31:24]
R/W R/W R/W R/W R/W R/W R/W R/W R/W
Bit 23 22 21 20 19 18 17 16
IP_ADDR[23:16]
R/W R/W R/W R/W R/W R/W R/W R/W R/W
Bit 15 14 13 12 11 10 9 8
IP_ADDR[15:8]
R/W R/W R/W R/W R/W R/W R/W R/W R/W
Bit 7 6 5 4 3 2 1 0
IP_ADDR[7:0]
R/W R/W R/W R/W R/W R/W R/W R/W R/W
 Bit 31:0 – IP address
These registers contain power supply IP address (available only if ETHERNET flag is set in
CARD_TYPE register).
IP_NETMASK – 0x5002 – IP network mask
Bit 15 14 13 12 11 10 9 8
‒
R/W R/W R/W R/W R/W R/W R/W R/W R/W
Bit 7 6 5 4 3 2 1 0
IP_NETMASK[7:0]
R/W R/W R/W R/W R/W R/W R/W R/W R/W
 Bit 15:8 – Unused bits
These bits are unused.
 Bit 7:0 – IP network mask
These bytes contains IP network mask (CIDR notation, available only if ETHERNET flag is set in
CARD_TYPE register).
MAC_ADDR – 0x5003 – Ethernet MAC address
Bit 47 46 45 44 43 42 41 40
MAC_ADDR[47:40]
