OPERATIONS
r
TRIGGER1
2
TRIGGER3
TRIGGER4
TRIGGER5
TRIGGER
2. TRIGGER SETTING
TRIGGER SETTING
2
SOURCE: [CAM1~4;AUX;SPLIT2~4]
DELAY: [0~20 sec]
1. User can use 5 triggers and each trigger source(CAM1~SPLIT4) can
be selected.
2. When the trigger is activated, the selected source’s image is displayed.
3. The Triggers have a priority difference according to the following
order:
Trigger1 -> Trigger2 -> Trigger3 -> Trigger4 -> Trigger5 -> Speed switch
Trigger1 has highest Speed switch has lowest
priority; priority.
Each trigger's delay time is adjustable from 0 sec to 20 sec.
If one camera is activated by an intermittent 12/24VDC signal
( e.g. from an indicator light) it must be delayed to prevent the
picture from flickering.
2
NOTE
SOURCE:
[CAM1~4;AUX;
SPLIT2~4]
DELAY : [0~20sec]
MARKER : [ON;OFF]
MARKER SETTING
UP / DN
TRIGGER1~TRIGGER5
UP / DN
TRIGGER1~TRIGGER5
MARKER:[ON;OFF]
1. ON/OFF setting for distance marker when any trigger is engaged.
A
A
Selecting
Selecting
SOURCE
SOURCE
SOURCE
SOURCE
Option setting
Option setting
Exit
Exit
MENU
MENU
Shifting
Shifting
Shifting
Shifting
UP / DN
UP / DN
UP / DN
UP / DN
MENU
MENU
UP
DN
UP
DN
UP
DN
UP
DN
SOURCE
SOURCE
- / +
+
- / +- / +
+
