Saftronics CIMR-VG5U User Manual

VG5 Installation & Quick-Start Manual 105
Operator
Function o2 Key Selections Function o1 Monitor Selection
O1-01
Monitor Selection
(User Monitor Sel)
4~39 1 6
Monitor selection
4: Control method
5: Motor speed
6: Output voltage
7: DC bus voltage
8: Output power
9: Torque reference (internal)
10: Input terminal status
11: Output terminal status
12: Internal Control Status 1
13: Elapsed time
14: Flash software ID number
15: External terminal 13 input
voltage
16: External terminal 14 input
voltage
17: External terminal 16 input
voltage
18: Motor secondary current (Iq)
19: Motor excitation current (Id)
20: Primary frequency after SFS
21: Speed controller ASR input
22: Speed controller ASR output
23: Speed deviation
24: PID feedback
25: DI-16 reference
26: Voltage reference (Vq out-
put)
27: Voltage reference (Vd out
put)
28: CPU ID number
o B B B B
O1-02
Monitor Selection
after Power Up
(Power- On Moni-
tor)
1~4 1 1
1: (Frequency Ref)
2: (Output Freq)
3: (Output Current)
4: (User Monitor)
o B B B B
O1-03
Frequency Units of
Reference Setting
and Monitor
(Display Scaling)
0~
39999
1 0 — x B B B B
O1-04 (Display Units) 0, 1 1 0
0: (Hertz)
1: (RPM)
x - - - B
O1-05
Parameter No. Dis-
play Selection
(Address Display)
0, 1 1 0
0: (Parameter Number)
1: (Memobus Address)
x A A A A
O2-01
LOCAL/REMOTE
Key Enable/Disable
(Local/Remote Key)
0, 1 1 1
0: (Disabled)
1: (Enabled)
x B B B B
O2-02
STOP Key Func-
tion Selection
(Oper STOP Key)
0, 1 1 1
0: (Disabled) When the inverter
is operated from the digital
operator.
1: (Enabled) Always enabled.
x B B B B
Function
Parameter
No.
Name
(Digital Operator
Display)
Setting
Range
Setting
Unit
Factory
Setting
Remarks
(Digital Operator Display)
Change
during
Operation
o: Enabled
x: Disabled
Parameter Access Level
User
Setting
V/f
V/f
w/
PG
Open
Loop
Vector
Flux
Vector
Appendix
VG5 Parameters
