VG5 Installation & Quick-Start Manual 11
VG5 SPECIFICATIONS (continued)
Control Characteristics
Control Method Sine wave PWM
Starting Torque 150% below 1Hz (150% at 0 rpm with PG)
Speed Control Range 100:1 (1000:1 with PG)
Speed Control Accuracy ±0.2% (±0.02% with PG)
Speed Response 5Hz (30Hz with PG)
Torque Limit Can be set by parameter: 4 quadrant control
Torque Accuracy ±5%
Torque Response 20Hz (40Hz with PG)
Frequency Control Range 0.1 to 400 Hz
Frequency Accuracy Digital command: 0.01%, Analog command: 0.1%
Frequency Setting
Resolution
Digital Operator Reference: 0.01Hz
Analog Reference: 0.03Hz (@60Hz)
Output Frequency
Resolution
0.01 Hz
Frequency Setting Signal -10 to +10V, 0 to +10V, 4 to 20mA
Accel/Decel Time
0.0 to 6000.0 sec.
(Accel/Decel time setting independently, 4 steps available)
Braking Torque Approx. 20%
Protective Functions
Motor Overload Protection
UL-recognized electronic thermal overload relay (I
2
T)
Instantaneous Overcurrent Motor coasts to stop at approximately 200% rated output current. (CT Rating)
Fuse Protection Motor coasts to stop at blown fuse.
Overload Motor coasts to stop after 1 min. at 150% rated output current. (CT Rating)
Overvoltage Motor coasts to stop if converter output voltage exceeds 410VDC (820VDC at 460V input, 1040VDC at 575V input)
Undervoltage Motor coasts to stop if converter output voltage drops below user adjustable value
Momentary Power Loss
Immediately stop after 15 ms or longer power loss. (Continuous system
operation during power loss less than 2s is equipped as standard.)
Heatsink Overheat Thermistor - OH1, OH2
Stall Prevention Stall prevention during acceleration, deceleration and constant speed operation
Ground Fault Provided by electronic circuit (overcurrent level)
Power Charge
Indication
Charge LED stays on until bus voltage drops below 50VDC
Input Phase Loss Single-phase protection
Environmental Conditions
Location Indoor (protected from corrosive gases and dust)
Ambient Temperature
+14 to 104°F (-10 to 40°C) for NEMA 1 type
+14 to 113°F (-10 to 45°C) for Open Chassis type
Storage Temperature -4 to 140°F (-20 to 60°C)
Humidity 95% RH (non-condensing)
Vibration
9.8m/s
2
(1G) less than 20Hz, up to 1.96m/s
2
(0.2G) at 20 to 50Hz
Chapter 1 - Receiving & Installation
Specifications
To Next Page
