Dimensions/Heat Loss (Continued)
Enclosed Type (NEMA 1, IP20)
Voltage
Model
CIMR-
VG5U
Open Chassis Dimensions in inches (mm)
Mass
lbs (kg)
Heat Loss (W)
W H D W1 H1 H2
Heat sink
Inside
unit
To tal
575V
51P5
5.51 (140) 11.02 (280) 7.09 (180) 4.96 (126) 10.47 (266) 0.28 (7) 8.8 (4)
35 55 90
52P2 45 60 105
53P7
7.87 (200) 11.81 (300) 8.07 (205) 7.32 (186) 11.22 (285) 0.31 (8)
13 (6) 65 75 140
55P5
14 (6.5)
100 105 205
57P5 130 90 220
5011
9.84 (250) 14.96 (380) 8.86 (225) 9.29 (236) 14.37 (365) 0.29 (7.5) 28 (13)
180 150 330
5015
250 210 460
5018
15.75 (400) 29.53 (750) 11.22 (285) 11.81 (300) 28.74 (730) 0.39 (10) 97 (44)
310 230 540
5022
380 340 730
5030
22.64 (575) 33.46 (850) 11.81 (300) 18.70 (475) 32.48 (825) 0.49 (12.5) 156 (72)
430 390 820
5037
680 540 1220
5045 900 750 1650
5055
22.64 (575) 41.34 (1050) 12.80 (325) 18.70 (475) 40.35 (1025) 0.49 (12.5) 195 (90)
1000 750 1750
5075
1100 1150 2250
5090
22.64 (575) 49.21 (1250) 12.99 (330) 18.70 (475) 48.23 (1225) 0.49 (12.5) 262 (121) 1150 1200 2350
5110
22.64 (575) 62.99 (1600) 13.98 (355) 18.70 (475) 61.81 (1570) 0.59 (15)
318 (147) 1400 1800 3200
5160 329 (152) 1870 2830 4700
Voltage
Model
(CIMR-VG5)
NEMA 1 Dimensions in inches (mm) Mass
lbs (kg)W H D W1 H1 H2
230V
20P4
5.51 (140) 11.02 (280) 6.30 (160) 4.96 (126) 10.47 (266) 0.28 (7) 6.5 (3)20P7
21P5
22P2
5.51 (140) 11.02 (280) 7.09 (180) 4.96 (126) 10.47 (266) 0.28 (7) 10 (4.5)
23P7
25P5
7.87 (200) 11.81 (300) 8.07 (205) 7.32 (186) 11.22 (285) 0.31 (8)
12 (5.5)
27P5
13 (6)
2011
9.84 (250)
14.96 (380)
8.86 (225) 9.29 (236) 14.37 (365)
0.30 (7.5)
24 (11)
2015 15.75 (400) 1.08 (27.5)
2018
12.99 (330)
24.02 (610)
11.22 (285) 10.83 (275) 17.13 (435)
3.44 (87.5)
71 (32)
2022 26.57 (675) 6.00 (152.5)
2030
16.93 (430) 38.78 (985) 13.78 (350) 12.60 (320) 25.59 (650) 8.37 (212.5)
148 (67)
2037
150 (68)
2045
18.90 (480) 43.70 (1110) 13.78 (350) 14.57 (370) 30.51 (775) 8.37 (212.5) 192 (87)
2055
2075 22.83 (580) 50.79 (1290) 15.75 (400) 17.52 (445) 35.24 (895) 10.63 (270) 320 (145)
Chapter 1 - Receiving & Installation
Mounting
Dimensions/Heat Loss (Continued)
Open Chassis Type (IP00)
