80 VG5 Installation & Quick-Start Manual
Group b Application
PID Control
B5-12
<1110>
PID Feedback Ref-
erence Missing
Detection Selection
(Fb Los Det Sel)
0~2 1 0
0: PID feedback missing
detection disabled. (Dis-
abled)
1: PID feedback missing
detection enabled. (Alarm)
Operation continues after
detection, “Fbl” alarm is dis-
played.
2: PID feedback missing
detection enabled. (Fault)
Inverter output is shut off
after detection, “Fbl” is dis-
played.
x A A A A
B5-13
<1110>
PID Feedback Ref-
erence Missing
Detection Level
(Fb los Det Lvl)
0~100 1% 0
—
x A A A A
B5-14
<1110>
PID Feedback Ref-
erence Missing
Detection Time
(Fb los Det Time)
0.0~
25.5
0.1s 1.0
—
x A A A A
Function b6 Reference Hold
B6-01
Dwell Frequency at
Start
(Dwell Ref @Start)
0.0~
400.0
0.1Hz 0.0 — x A A A A
B6-02
Dwell Time at Start
(Dwell Time @
Start)
0.0~
10.0
0.1s 0.0 — x A A A A
B6-03
Dwell Frequency at
Stop
(Dwell Ref @ Stop)
0.0~
400.0
0.1Hz 0.0 — x A A A A
B6-04
Dwell Time at Stop
(Dwell Time @
Stop)
0.0~
10.0
0.1s 0.0 — x A A A A
Function b7 Droop Control
Droop Control
B7-01
Droop Control Gain
(Droop Quantity)
0.0~
100.0
0.1% 0.0 — o - - - A
B7-02
Droop Control
Delay Time
(Droop Delay Time)
0.03~
2.00
0.01s 0.05 — o - - - A
Function
Parameter
No.
Name
(Digital Operator
Display)
Setting
Range
Setting
Unit
Factory
Setting
Remarks
(Digital Operator Display)
Change
during
Operation
o: Enabled
x: Disabled
Parameter Access Level
User
Setting
V/f
V/f
w/
PG
Open
Loop
Vector
Flux
Vector
Appendix
VG5 Parameters
