4
SH6- HEATER CONTROLLER SERIES
1.3.1 SH6 INPUT DATA
NOTE: The stack input voltage and the control circuit
supply must be synchronised i.e. R to R, S to S, T to T!!
STACK INPUT:
Voltage Type
SCR Voltage Rating
- 3 Phase Input
- 2,5 x line-line
AC
Voltage (min)
Type SH6-XX-3 - 420V Max Continuous
RMS voltage
Type SH6-XX-5 - 580V Max Continuous
RMS Voltage
Line Frequency - 50Hz +2Hz
PC550 CONTROL SUPPLY
Voltage Type - 3 Phase Input
Selectable 380/525V
Link at 380V Position - 340v - 420v
Link at 525V Position - 470v - 580v
Line Current - Less that 25mA
Line Frequency - 50Hz ± 2Hz
FAN SUPPLY
Type SH6 -100 to SH6-800 - AC220V, 50Hz, 0,5A
1.3.2 SH6 OUTPUT DATA
Unless otherwise specified, the currents listed below are
maximum at a maximum ambient temp of 40 DegºC and at an
altitude of 1500m max.
OUTPUT CURRENT
Type SH6 - 100 - 100 A Max. Cont. Current
