SH6- HEATER CONTROLLER SERIES

Type SH6 - 150

150A Max. Cont. Current

Type SH6 - 200

200A Max. Cont. Current

Type SH6 - 300 - 300A Max. Cont. Current

Type SH6 - 400 - 400A Max. Cont. Current

Type SH6 - 600 - 600A Max. Cont. Current

Type SH6 - 800 - 800A Max. Cont. Current

OVER CURRENT

Amount - 110% (Max Continuous Current) Max

Different ratings available on request.

DERATING

At higher temperature than 40 Deg. C. - 1.5% per 1 Deg.C.

At higher altitude than 1500m - 1% per 100m

1.4 PROTECTIVE MEASURES

In order to ensure high system reliability protective measures

have been taken which protect both the controller and the

load.

NOTE: For complete protection of the SH6 heater controller high

speed input fuses must be installed.

1.4.1 DRIVE PROTECTION MEASURES
