SH6- HEATER CONTROLLER SERIES
7
2. MECHANICAL LAYOUT AND MOUNTING
2.1 UNIT DIMENSIONS
The complete range of SH6 soft starters are divided into 4
physical sizes. Namely Size B,C,D and E.
WARNING : ISOLATE
BEFORE REM OVING
COVER.
DO NOT LIFT ON COVER
DANGE R! LIVE BUSB ARS
FIG 2.1 - SH6 SERIES - SIZE B OVERALL DIMENSIONS
