Saftronics SH6 Series - Technical Data

3
SH6- HEATER CONTROLLER SERIES
TABLE 1.1 380v SH6 SERIES
TYPE
LOAD
POWER
(380 V)
LOAD
POWER
(525 V)
(NOMINAL)
LINE
VOLTAGE
LOAD
CURRENT
SIZE
SH6 – 100
69 kW
90 kW
380V / 525V
100 Amps
B
SH6 – 150
100 kW
135 kW
380V / 525V
150 Amps
B
SH6 – 200
130 kW
180 kW
380V / 525V
200 Amps
B
SH6 – 300
200 kW
275 kW
380V / 525V
300 Amps
C
SH6 – 400
260 kW
360 kW
380V / 525V
400 Amps
D
SH6 – 600
400 kW
550 kW
380V / 525V
600 Amps
E
SH6 - 800
525 KW
730 KW
380V / 525V
800 Amps
E
The SH6 range of heater controllers come in three
configurations.
1.2.1 KIT FORM (CHASSIS) for mounting into a customer's
enclosure.
This consists of thyristor stack and PC550 control card
only.
1.2.2 KIT FORM (ENCLOSED) for mounting between an
existing MCC and ELEMENTS.
This consists of thyristor stack and PC550 control card
in an IP23 enclosure.
1.2.3 STANDARD FORM
This is a complete heater controller consisting of;
thyristor stack, PC550 control card. isolator, high speed
fuses, potentiometer and stop/start pushbuttons in an
IP23 enclosure.
1.2.4 OPTIONAL FEATURES
1 Multi motor starting
2 Line disconnect
3 Line fuses
4 Isolating contactor
5 Start / Stop pushbuttons
6 Bypass contactor
1.3 TECHNICAL DATA
