82 VG5 Installation & Quick-Start Manual
Group C Tuning
Function C1 Accel / Decel
C1-01
Acceleration Time 1
(Accel Time 1)
Depends
on
C1-10
0.00~
600.00
or
0.0
~
6000.0
Depends
on
C1-10
0.01s or
0.1s
10.0 — o Q Q Q Q
C1-02
Deceleration Time 1
(Decel Time 1)
10.0 — o Q Q Q Q
C1-03
Acceleration Time 2
(Accel Time 2)
10.0 — o B B B B
C1-04
Deceleration Time 2
(Decel Time 2)
10.0 — o B B B B
C1-05
Acceleration Time 3
(Accel Time 3)
10.0 — x A A A A
C1-06
Deceleration Time 3
(Decel Time 3)
10.0 — x A A A A
C1-07
Acceleration Time 4
(Accel Time 4)
10.0 — x A A A A
C1-08
Deceleration Time 4
(Decel Time 4)
10.0 — x A A A A
C1-09
Emergency Stop
Time
(Fast Stop Time)
10.0 — x B B B B
C1-10
Accel/Decel Time
Set Unit
(Acc/Dec Units)
0.1 1 1
0:Set unit of accel/decel time is
0.01s. (0.01 Seconds)
1:Set unit of accel/decel time is
0.1s. (0.1 Seconds)
x A A A A
C1-11
Accel/Decel Time
Switching
Frequency
(Acc/Dec SW Freq)
0.0~
400.0
0.1Hz 0.0 — x A A A A
Function
Parameter
No.
Name
(Digital Operator
Display)
Setting
Range
Setting
Unit
Factory
Setting
Remarks
(Digital Operator Display)
Change
during
Operation
o: Enabled
x: Disabled
Parameter Access Level
User
Setting
V/f
V/f
w/
PG
Open
Loop
Vector
Flux
Vector
Appendix
VG5 Parameters
