Model F@st™2864 Router User’s Guide Physical Installation
5
The figures below show the connectors and labeling on the rear, top and bottom of the F@st™2864.
Rear Top Bottom
USB 1 WAN ETH HPNALAN 1 LAN 2 LAN 3 LAN 4
USB 2
RESET DSL POWER
