Model F@st™2864 Router User’s Guide Physical Installation
6
LEDs / Push Buttons
The figures below show the LEDs and push buttons from the side and front of the F@st™2864.
Side Front
The figure below defines the icons for the LEDs and push buttons on the F@st™2864.
Power
HPNA
WAN
Internet
TV
Wireless
WPS
1
st
LED
2
nd
LED
3
rd
LED
4
th
LED
5
th
LED
6
th
LED
7
th
LED
N/A
Wireless
WPS
1
st
Button
2
nd
Button
3
rd
Button
N/A
F@st™2864 – Front Panel LED and Button Labelling
LEDs Buttons
Note that the rear Ethernet connectors contain yellow (10/100Mbps) and green (1000Mbps) LEDs.
