Sailor RT2048 VHF User Manual

Page 7-3
BASE UNIT RT2048 STD. T&T A/S 702048
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
VARIOUS SILICONE SEAL FOR CABINET NORD.ELEKTR. 0-4-25397A 48.585
632-2456-00-X
VARIOUS KNOB Ø10mm SANDER PLAST 0-3-25432A 48.693
VARIOUS FUSE COVER SANDER PLAST Tg.Nr: 0-3-25362B 48.696
VARIOUS COVER FOR ALLEN SCREW SANDER PLAST 0-3-25350A 48.699
VARIOUS CONNECTION CABLE FOR LOUDSPEAKER AFD.32 3-0-25463 525463
VARIOUS MAIN INTERCONNECTION CABLE RT2048 3M 3-0-25462B 56.004
VARIOUS ANTENNA JACK (FEMALE) SO239 KAJ V HANSEN SO239 78.504
VARIOUS SCREW PT Ø2.9 x 16MM A2 EJOT GMBH KB30x16 WN-1442/A2 88.103
VARIOUS COAX CABLE Ø3x23cm T&T A/S 3-0-25471 525471
VARIOUS COAX CABLE Ø3x23cm T&T A/S 3-0-25471 525471
-1 KEYBOARD MODULE RT2048 T&T A/S 5-0-25447 625447
-2 INTERFACE MODULE RT2048 T&T A/S 5-0-25450K / 4-0-25450N 625450
-3 SYNTESE MODULE RT2048 T&T A/S 5-0-25451H / 4-0-25451P 625451
-4 RX/TX MODULE RT2048 T&T A/S 5-0-25448L / 4-0-25448K 625448
-5 SELCALL MODULE (OPTIONAL) RT2048 T&T A/S 5-0-25449B / 4-0-25449D 625449
VARIOUS MICROTELEPHONE FOR CRY2001, RT2048 & RE2100 T&T A/S 700118 MICROTELEPHONE 700118
LS1 LOUDSPEAKER 4 OHMS 15W 88x88mm RIGHT ELEC. S-881252-035P 46.052
KEYBOARD MODULE RT2048 T&T A/S 5-0-25447 625447
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
D1-1 DIODE LIGHT EMITTING SUB MINIATURE YELLOW H.P. HLMP-7019 25.649
D2-1 DIODE LIGHT EMITTING SUB MINIATURE YELLOW H.P. HLMP-7019 25.649
D3-1 DIODE LIGHT EMITTING SUB MINIATURE YELLOW H.P. HLMP-7019 25.649
D4-1 DIODE LIGHT EMITTING SUB MINIATURE YELLOW H.P. HLMP-7019 25.649
D5-1 DIODE LIGHT EMITTING SUB MINIATURE YELLOW H.P. HLMP-7019 25.649
D6-1 DIODE LIGHT EMITTING SUB MINIATURE YELLOW H.P. HLMP-7019 25.649
J1-1 INTERCONNECTION CABLE 10 POLES L=60mm MOLEX 3-0-25465B 56.003
R1-1 RESISTOR MF 330 OHM 5% 0.4W PHILIPS 2322 181 53331 01.187
R2-1 RESISTOR MF 330 OHM 5% 0.4W PHILIPS 2322 181 53331 01.187
S1-1 SWITCH KEYBOARD 12x12mm ALPS SKHCAD (KHC 10904) 43.601
S2-1 SWITCH KEYBOARD 12x12mm ALPS SKHCAD (KHC 10904) 43.601
S3-1 SWITCH KEYBOARD 12x12mm ALPS SKHCAD (KHC 10904) 43.601
S4-1 SWITCH KEYBOARD 12x12mm ALPS SKHCAD (KHC 10904) 43.601
S5-1 SWITCH KEYBOARD 12x12mm ALPS SKHCAD (KHC 10904) 43.601
S6-1 SWITCH KEYBOARD 12x12mm ALPS SKHCAD (KHC 10904) 43.601
S7-1 SWITCH KEYBOARD 12x12mm ALPS SKHCAD (KHC 10904) 43.601
S8-1 SWITCH KEYBOARD 12x12mm ALPS SKHCAD (KHC 10904) 43.601
S9-1 SWITCH KEYBOARD 12x12mm ALPS SKHCAD (KHC 10904) 43.601
S10-1 SWITCH KEYBOARD 12x12mm ALPS SKHCAD (KHC 10904) 43.601
S11-1 SWITCH KEYBOARD 12x12mm ALPS SKHCAD (KHC 10904) 43.601
S12-1 SWITCH KEYBOARD 12x12mm ALPS SKHCAD (KHC 10904) 43.601
INTERFACE MODULE RT2048 T&T A/S 4-6-25450L / 4-0-25450P 625450
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
VARIOUS SOCKET DIL 2x20 POLES AMP 641606-3 30.935
VARIOUS CONNECTION CABLE FOR VOLUME CONTROL RT2048 T&T A/S 3-0-25466 525466
VARIOUS SOCKET 1/10" SIL 10 POLES PRECI-DIP 311-91-110 78.803
C1-2 CAPACITOR MKT 150nF 5% 50VDC ERO MKT 1826-415/06 4-G 11.181
C2-2 CAPACITOR ELECTROLYTIC 10uF 20% 35VDC ELNA RJ2-35-V-100-M-T58 14.512
C3-2 CAPACITOR POLYPROPYLENE 2n2F 5% 100VDC ERO KP 1830-222/01-4-GW 13.400
C4-2 CAPACITOR CERAMIC 18pF 5% NPO 500VDC KCK RT-HM60 SK CH 180 J 15.060
C5-2 CAPACITOR CERAMIC 150pF 2% N150 100VDC PHILIPS 2222 689(679) 34151 15.148
C6-2 CAPACITOR CERAMIC 150pF 2% N150 100VDC PHILIPS 2222 689(679) 34151 15.148
C7-2 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C8-2 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C9-2 CAPACITOR CERAMIC 1n0F 10% CL2 500VDC KCK RT-HM60 SK YB 102 K 15.160
C10-2 CAPACITOR MKT 22nF 5% 100VDC PHILIPS 2222 370 89223 11.169
C11-2 CAPACITOR ELECTROLYTIC 220uF -20/+50% 16VDC ELNA RJ2-16-V-221-M-T2 14.640
0820
7 PARTS LIST RT2048
