7 PARTS LIST RT2048
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
C12-2 CAPACITOR ELECTROLYTIC 2m2F 20% 16VDC SAMHWA ELEC. SV-2200uF-16WV 14.713
C13-2 CAPACITOR MKT 470nF 5% 63VDC ERO MKT 1826-447/06 4-G 11.187
C14-2 CAPACITOR MKT 15nF 5% 63VDC PHILIPS 2222 370 89153 11.173
C15-2 CAPACITOR ELECTROLYTIC 10uF 20% 35VDC ELNA RJ2-35-V-100-M-T58 14.512
C16-2 CAPACITOR ELECTROLYTIC 10uF 20% 35VDC ELNA RJ2-35-V-100-M-T58 14.512
C17-2 CAPACITOR MKT 0.1uF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C18-2 CAPACITOR MKT 220nF 5% 63VDC PHILIPS 2222 370 79224 11.182
C19-2 CAPACITOR MKT 220nF 20% 63VDC ERO MKT 1826-422/06 6-G 11.183
C20-2 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C21-2 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C22-2 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C23-2 CAPACITOR CERAMIC 1n0F 10% CL2 500VDC KCK RT-HM60 SK YB 102 K 15.160
C24-2 CAPACITOR CERAMIC 1n0F 10% CL2 500VDC KCK RT-HM60 SK YB 102 K 15.160
C25-2 CAPACITOR CERAMIC 1n0F 10% CL2 500VDC KCK RT-HM60 SK YB 102 K 15.160
C26-2 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C27-2 CAPACITOR POLYPROPYLENE 1n0F 5% 100VDC ERO KP 1830-210/01-4-GW 13.398
D1-2 DIODE RECTIFIER 1N4002 100V/1A MOTOROLA 1N4002(03/04/05/06/07)RL 25.100
D2-2 DIODE ZENER 4V7 2% 0.4W BZX79B4V7 PHILIPS BZX79B4V7 26.496
D3-2 DIODE LIGHT EMITTING REDSQUARE 5x5mm KINGBRIGHT L-1553 IDT 25.538
D4-2 DIODE LIGHT EMITTING YELLOW SQUARE 5x5mm KINGBRIGHT L-1553 YDT 25.539
D5-2 DIODE LIGHT EMITTING REDSQUARE 5x5mm KINGBRIGHT L-1553 IDT 25.538
D6-2 DISPLAY 7SEGMENT LED HDSP-5551 RED HP HDSP-5551 25.725
D7-2 DISPLAY 7SEGMENT LED HDSP-5551 RED HP HDSP-5551 25.725
D8-2 DIODE BAW62 HIGH SPEED PHILIPS BAW62-143 25.350
D9-2 DIODE SCHOTTKY BAT 43 THOMSON-CSF BAT43 27.600
D10-2 DIODE ZENER 5.1V 2% 0.4W BZX79B5V1 PHILIPS BZX79B5V1 26.497
J1-2 SOCKET 10 POLES F.RIBBON CABLE MOLEX 52011-1010 78.283
J2-2 SOCKET 7 POLES F.RIBBON CABLE MOLEX 52011-0710 78.280
J3-2 SOCKET COAX 90 DEG. PCB VERSION TAIKO TMP-J01X-V6 78.518
J4-2 SOCKET COAX 90 DEG. PCB VERSION TAIKO TMP-J01X-V6 78.518
L1-2 FERRITE BEAD INDUCTOR DOUBLE BEAD CORE MURATA BL02RN2-R62T2 35.300
L2-2 FERRITE BEAD INDUCTOR DOUBLE BEAD CORE MURATA BL02RN2-R62T2 35.300
L3-2 CHOKE FIXED 120uH 10% FASTRON MICC-121K-02 20.372
P1-2 MULTIPLUG 2x15 POLES PCB VERSION 3M 3531-6002 / 7630-6002 JL 78.253
P2-2 SIL SQUARE PINS 2 POLES CC=1/10" AMP 0-826629-2 78.322
(0-826647-2)
P3-2 SIL SQUARE PINS 2 POLES CC=1/10" AMP 0-826629-2 78.322
(0-826647-2)
Q1-2 TRANSISTOR AF BC328-25 PNP TO-92 PHILIPS BC328-25-126 28.052
Q2-2 TRANSISTOR AF BC338-25 NPN TO-92 PHILIPS BC338-25-126 28.058
Q3-2 TRANSISTOR J FET N CHANNEL BF245A PHILIPS BF245A-126 29.714
Q4-2 TRANSISTOR AF BC328-25 PNP TO-92 PHILIPS BC328-25-126 28.052
Q5-2 TRANSISTOR AF BC558B PHILIPS BC558B-126 28.100
Q6-2 TRANSISTOR AF BC548B NPN TO-92 PHILIPS BC548B-126 28.076
Q7-2 TRANSISTOR AF BC548B NPN TO-92 PHILIPS BC548B-126 28.076
Q8-2 TRANSISTOR AF BC548B NPN TO-92 PHILIPS BC548B-126 28.076
R1-2 RESISTOR MF 22k OHM 5% 0.4W PHILIPS 2322 181 53223 01.233
R2-2 RESISTOR MF 22k OHM 5% 0.33W PHILIPS 2322 187 73223 02.504
R3-2 RESISTOR MF 150 OHM 5% 0.4W PHILIPS 2322 181 53151 01.179
R4-2 RESISTOR 0 OHM PHILIPS 2322 181 90018 01.110
R6-2 RESISTOR MF 36k5 OHM 1% 0.6W PHILIPS 2322 156 13653 03.438
R7-2 RESISTOR MF 2k7 OHM 5% 0.4W PHILIPS 2322 181 53272 01.210
R8-2 RESISTOR MF 1k5 OHM 5% 0.4W PHILIPS 2322 181 53152 01.204
R9-2 RESISTOR MF 100 OHM 5% 0.4W PHILIPS 2322 181 53101 01.175
R10-2 POTENTIOMETER 50k OHM 20% 50mW LOG NOBLE 779-9013 08.286
R11-2 RESISTOR ARRAY 4x5k6 OHM 5% 1/4W BOURNS 4608X-102-562 08.626
R12-2 RESISTOR MF 97k6 OHM 1% 0.6W PHILIPS 2322 156 19763 03.471
R13-2 RESISTOR MF 1k21 OHM 1% 0.6W PHILIPS 2322 156 11212 03.227
R14-2 RESISTOR MF 33k2 OHM 1% 0.6W PHILIPS 2322 156 13323 03.232
R15-2 RESISTOR MF 270k OHM 1% 0.6W PHILIPS 2322 156 12704 03.465
R16-2 RESISTOR MF 4k32 OHM 1% 0.6W PHILIPS 2322 156 14322 03.415
R17-2 RESISTOR MF 120k OHM 5% 0.4W PHILIPS 2322 181 53124 01.252
R18-2 RESISTOR MF 91k OHM 5% 0.4W PHILIPS 2322 181 53913 01.248
R19-2 RESISTOR MF 330k OHM 1% 0.6W PHILIPS 2322 156 13304 03.270
R20-2 RESISTOR MF 10k OHM 5% 0.4W PHILIPS 2322 181 53103 01.225
R21-2 RESISTOR MF 150k OHM 5% 0.4W PHILIPS 2322 181 53154 01.254
R22-2 RESISTOR MF 10k OHM 5% 0.4W PHILIPS 2322 181 53103 01.225
R23-2 POTENTIOMETER 10k OHM 10% 0.1W LOG NOBLE V90-10155-D 08.257
R24-2 RESISTOR ARRAY 8x100k OHM 5% 1/8W BOURNS 4609X-101-104 08.655
R25-2 RESISTOR MF 10k OHM 5% 0.4W PHILIPS 2322 181 53103 01.225
R26-2 RESISTOR MF 51k0 OHM 1% 0.6W PHILIPS 2322 156 15103 03.462
R27-2 RESISTOR MF 270k OHM 1% 0.6W PHILIPS 2322 156 12704 03.465
R28-2 RESISTOR ARRAY 4x10k OHM 5% 1/8W PANASONIC EXBF8V103G (4X10K) 08.615
0820
Page 7-4
