7 PARTS LIST RT2048
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
R29-2 RESISTOR ARRAY 4x10k OHM 5% 1/8W PANASONIC EXBF8V103G (4X10K) 08.615
R30-2 RESISTOR MF 3k3 OHM 5% 0.4W PHILIPS 2322 181 53332 01.212
R31-2 RESISTOR MF 100k OHM 5% 0.4W PHILIPS 2322 181 53104 01.250
R32-2 RESISTOR MF 3k48 OHM 1% 0.6W PHILIPS 2322 156 13482 03.400
R33-2 RESISTOR ARRAY 4x820 OHM 5% 0.25W PANASONIC EXBF8V821G (4X820R) 08.601
R34-2 RESISTOR ARRAY 4x820 OHM 5% 0.25W PANASONIC EXBF8V821G (4X820R) 08.601
R35-2 RESISTOR ARRAY 4x820 OHM 5% 0.25W PANASONIC EXBF8V821G (4X820R) 08.601
R36-2 RESISTOR ARRAY 4x820 OHM 5% 0.25W PANASONIC EXBF8V821G (4X820R) 08.601
R38-2 RESISTOR ARRAY 4x10k OHM 5% 1/8W PANASONIC EXBF8V103G (4X10K) 08.615
R39-2 RESISTOR MF 8k25 OHM 1% 0.6W PHILIPS 2322 156 18252 03.423
R40-2 RESISTOR MF 10k0 OHM 1% 0.6W PHILIPS 2322 156 11003 03.427
R41-2 RESISTOR MF 15k0 OHM 1% 0.6W PHILIPS 2322 156 11503 03.429
R42-3 RESISTOR ARRAY 4x330 OHM 5% 1/4W BOURNS 4608X-102-331 08.608
R43-2 RESISTOR MF 47 OHM 5% 0.4W PHILIPS 2322 181 53479 01.166
R44-2 RESISTOR MF 1k0 OHM 5% 0.4W PHILIPS 2322 181 53102 01.200
R45-2 RESISTOR MF 3k9 OHM 5% 0.4W PHILIPS 2322 181 53392 01.214
R46-2 RESISTOR MF 750 OHM 5% 0.4W PHILIPS 2322 181 53751 01.196
R47-2 RESISTOR MF 18k OHM 5% 0.4W PHILIPS 2322 181 53183 01.231
R48-2 RESISTOR MF 820 OHM 5% 0.4W PHILIPS 2322 181 53821 01.197
R49-2 RESISTOR MF 15k OHM 5% 0.4W PHILIPS 2322 181 53153 01.229
R50-2 RESISTOR MF 270k OHM 1% 0.6W PHILIPS 2322 156 12704 03.465
R54-2 RESISTOR MF 4k7 OHM 5% 0.4W PHILIPS 2322 181 53472 01.216
R55-2 RESISTOR MF 3k3 OHM 5% 0.4W PHILIPS 2322 181 53332 01.212
R56-2 RESISTOR MF 4k7 OHM 5% 0.4W PHILIPS 2322 181 53472 01.216
R57-2 RESISTOR MF 3k3 OHM 5% 0.4W PHILIPS 2322 181 53332 01.212
R58-2 RESISTOR MF 100k OHM 5% 0.4W PHILIPS 2322 181 53104 01.250
R59-2 RESISTOR MF 5k11 OHM 1% 0.6W PHILIPS 2322 156 15112 03.414
R60-2 RESISTOR MF 357 OHM 1% 0.6W PHILIPS 2322 156 13571 02.204
U1-2 EEPROM 1k BIT SERIAL 93C46 NATIONAL NM93C46N 32.709
U2-2 EEPROM 1k BIT SERIAL 93C46 NATIONAL NM93C46N 32.709
U3-2 INTEGRATED CIRCUIT CPU PROGRAMMED (C1106) MOTOROLA SP.SPEC: C1106 32.563
ZC No: <427281P>
U4-2 8 BIT SHIFT REG.SERIAL IO 74HC595 MOTOROLA MC74HC595P / MC74HC595AN 34.502
U5-2 8 BIT SHIFT REG.SERIAL IO 74HC595 MOTOROLA MC74HC595P / MC74HC595AN 34.502
U6-2 8 BIT SHIFT REG.SERIAL IO 74HC595 MOTOROLA MC74HC595P / MC74HC595AN 34.502
U7-2 QUAD VOLTAGE COMPERATOR LM339 NATIONAL LM339N 31.075
U8-2 QUAD OP.AMP. 324 NAT/SGS LM324N 31.065
U9-2 VOLTAGE REG. ADJUSTABLE Io=0.1A LM317L MOTOROLA LM317LZ RA 31.145
SYNTESE MODULE RT2048 T&T A/S 5-0-25451H / 4-0-25451R 625451
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
NORTON NORMOUNT V1300 0.8x12mm 95.512
C1-3 CAPACITOR MKT 0.1uF 10% 63VDC PHILIPS 2222 370 78104 11.136
C2-3 CAPACITOR MKT 220nF 10% 63VDC PHILIPS 2222 370 78224 11.095
C3-3 CAPACITOR POLYSTYRENE 56pF 1% 630V PHILIPS 2222 431 85609 10.394
C4-3 CAPACITOR POLYSTYRENE 300pF 1% 630VDC PHILIPS 2222 431 83001 10.414
C5-3 CAPACITOR ELECTROLYTIC 100uF -10/+50% 25VDC ERO EKM 00 CC 310 E G5 14.610
C6-3 CAPACITOR POLYSTYRENE 51pF 1% 630V PHILIPS 2222 431 85109 10.393
C7-3 CAPACITOR MKT 22nF 10% 100VDC PHILIPS 2222 370 88223 11.175
C8-3 CAPACITOR MKT 22nF 10% 100VDC PHILIPS 2222 370 88223 11.175
C9-3 CAPACITOR MKT 22nF 10% 100VDC PHILIPS 2222 370 88223 11.175
C10-3 CAPACITOR MKT 220nF 10% 63VDC PHILIPS 2222 370 78224 11.095
C11-3 CAPACITOR MKT 22nF 10% 100VDC PHILIPS 2222 370 88223 11.175
C12-3 CAPACITOR ELECTROLYTIC 47uF 20% 25VDC ELNA RJ2-25-V-470-M-F1 14.524
C13-3 CAPACITOR MKT 220nF 5% 63VDC PHILIPS 2222 370 79224 11.182
C14-3 CAPACITOR ELECTROLYTIC 22uF 20% 35VDC ELNA RJ2-35-V-220-M-F1 14.516
C15-3 CAPACITOR ELECTROLYTIC 10uF 20% 35VDC ELNA RJ2-35-V-100-M-T34(T58) 14.512
C16-3 CAPACITOR ELECTROLYTIC 4.7uF 20% 50VDC ELNA RJ2-50-V-4R7-M-T34 14.510
C17-3 CAPACITOR MKT 1u5F 10% 50VDC ERO MKT 1826 515/05 5-G 11.191
C18-3 CAPACITOR POLYSTYRENE 12n1F 1% 63VDC PHILIPS 2222 443 41213 10.796
C19-3 CAPACITOR ELECTROLYTIC 1uF 20% 50VDC ELNA RJ2-50-V-010-M-T34 14.506
C20-3 CAPACITOR CERAMIC 39pF 5% NPO 50VDC KCK RT-HE50 SK CH 390 J 15.085
C21-3 CAPACITOR CERAMIC 5p6F +/-0.25pF NPO 500VDC KCK RT-HM60 SK CH 5R6 C 15.015
C22-3 CAPACITOR CERAMIC 1nOF 10% CL2 500VDC KCK RT-HM60 SK YB 102 K 15.160
C23-3 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C24-3 CAPACITOR CERAMIC 6p8F +/-0.25pF NPO 100VDC PHILIPS 2222 689 09688 15.325
C25-3 CAPACITOR CERAMIC 1nOF 10% CL2 500VDC KCK RT-HM60 SK YB 102 K 15.160
C26-3 CAPACITOR CERAMIC 1nOF 10% CL2 500VDC KCK RT-HM60 SK YB 102 K 15.160
C27-3 CAPACITOR CERAMIC 1nOF 10% CL2 500VDC KCK RT-HM60 SK YB 102 K 15.160
0820
Page 7-5
