7 PARTS LIST RT2048
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
R79-3 RESISTOR MF 47 OHM 5% 0.4W PHILIPS 2322 181 53479 01.166
R80-3 RESISTOR MF 1k6 OHM 5% 0.4W PHILIPS 2322 181 53162 01.205
R81-3 RESISTOR MF 4.3k OHM 5% 0.4W PHILIPS 2322 181 53432 01.215
R82-3 RESISTOR MF 3k3 OHM 5% 0.4W PHILIPS 2322 181 53332 01.212
R83-3 RESISTOR MF 560 OHM 5% 0.4W PHILIPS 2322 181 53561 01.193
R84-3 RESISTOR MF 300 OHM 5% 0.4W PHILIPS 2322 181 53301 01.186
R85-3 RESISTOR MF 100 OHM 5% 0.4W PHILIPS 2322 181 53101 01.175
R86-3 RESISTOR MF 300 OHM 5% 0.4W PHILIPS 2322 181 53301 01.186
R87-3 RESISTOR MF 18 OHM 5% 0.4W PHILIPS 2322 181 53189 01.156
R88-3 RESISTOR MF 56 OHM 5% 0.4W PHILIPS 2322 181 53569 01.168
R89-3 RESISTOR MF 5k1 OHM 5% 0.4W PHILIPS 2322 181 53512 01.217
R90-3 RESISTOR MF 75 OHM 5% 0.4W PHILIPS 2322 181 53759 01.171
R91-3 RESISTOR MF 1k8 OHM 5% 0.4W PHILIPS 2322 181 53182 01.206
R92-3 RESISTOR MF 68 OHM 5% 0.4W PHILIPS 2322 181 53689 01.170
R93-3 RESISTOR MF 8R2 OHM 5% 0.4W PHILIPS 2322 181 53828 01.147
R94-3 RESISTOR MF 330 OHM 5% 0.4W PHILIPS 2322 181 53331 01.187
R95-3 PRESET CERMET 250k OHM 10% 0.5W BOURNS 3386P-1-254 07.895
R96-3 PRESET CERMET 2k0 OHM 5% 0.5W BOURNS 3386P-1-202-11 07.887
R97-3 PRESET CERMET 250k OHM 10% 0.5W BOURNS 3386P-1-254 07.895
R98-3 PRESET CERMET 1k0 OHM 10% 0.5W BOURNS 3386P-1-102 07.886
U1-3 QUAD OP.AMP. 324 NAT/SGS LM324N 31.065
U2-3 DUAL D-FF POS TRIG. 74HC74 TEXAS SN74HC74N 34.501
U3-3 SERIAL INPUT PLL SYNTHES. MC145158P2 MOTOROLA MC145158P2 33.492
U4-3 INTEGRATED CIRCUIT MC12015P MOTOROLA MC12015P 32.850
X1-3 CRYSTAL C1074 14.850MHz 10ppm Precision Devices UK C1074 / PS0914 39.839
RX/TX MODULE RT2048 T&T 5-0-25448M / 4-0-25448L 625448
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
VARIOUS SHUNT CONNECTOR FEMALE 2 POLES AMP 142270-1 78.325
VARIOUS FUSECLIP FOR 20x5mm FUSELINK KEYSTONE CAT.NO.3521 78.396
C1-4 CAPACITOR CERAMIC 2p7F +/-0.25pF NPO 100VDC PHILIPS 2222 689 09278 15.320
C2-4 CAPACITOR ELECTROLYTIC 1000uF 20% 35VDC SAMHWA ELEC. SV-1000uF-35WV 14.655
C3-4 CAPACITOR MKT 0.1uF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C4-4 CAPACITOR ELECTROLYTIC 4.7uF 20% 50VDC ELNA RJ2-50-V-4R7-M-T58 14.510
C5-4 CAPACITOR ELECTROLYTIC 22uF 20% 25VDC ELNA RJ2-25-V-220-M-T58 14.514
C6-4 CAPACITOR ELECTROLYTIC 22uF 20% 25VDC ELNA RJ2-25-V-220-M-T58 14.514
C7-4 CAPACITOR ELECTROLYTIC 33uF 20% 16VDC ELNA RJ2-16-V-330-M-T58 14.518
C8-4 CAPACITOR ELECTROLYTIC 33uF 20% 16VDC ELNA RJ2-16-V-330-M-T58 14.518
C9-4 CAPACITOR ELECTROLYTIC 33uF 20% 16VDC ELNA RJ2-16-V-330-M-T58 14.518
C10-4 CAPACITOR ELECTROLYTIC 33uF 20% 16VDC ELNA RJ2-16-V-330-M-T58 14.518
C11-4 CAPACITOR MKT 0.1uF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
R12-4 CAPACITOR MKT 0.1uF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C13-4 CAPACITOR CERAMIC 10pF 5% NPO 500VDC KCK RT-HM60 SK CH 100 J 15.565
C14-4 CAPACITOR CERAMIC 10pF 5% NPO 500VDC KCK RT-HM60 SK CH 100 J 15.565
C15-4 CAPACITOR CERAMIC 18pF 5% NPO 500VDC KCK RT-HM60 SK CH 180 J 15.060
C16-4 CAPACITOR CERAMIC 15pF 5% NPO 500VDC KCK RT-HM60 SK CH 180 J 15.055
C17-4 CAPACITOR ELECTROLYTIC 10uF 20% 35VDC ELNA RJ2-35-V-100-M-T58 14.512
C18-4 CAPACITOR ELECTROLYTIC 10uF 20% 35VDC ELNA RJ2-35-V-100-M-T58 14.512
C19-4 CAPACITOR MKT 0.1uF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C20-4 CAPACITOR MKT 0.1uF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C21-4 CAPACITOR MKT 0.1uF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C22-4 CAPACITOR MKT 0.1uF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C23-4 CAPACITOR MKT 0.1uF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C24-4 CAPACITOR MKT 0.1uF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C25-4 CAPACITOR CERAMIC 51pF 5% NPO 50VDC KCK RT-HE60-SK CH 510 J 15.110
C26-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C27-4 CAPACITOR CERAMIC 51pF 5% NPO 50VDC KCK RT-HE60-SK CH 510 J 15.110
C28-4 CAPACITOR CERAMIC 51pF 5% NPO 50VDC KCK RT-HE60-SK CH 510 J 15.110
C29-4 CAPACITOR CERAMIC 22pF 5% NPO 500VDC KCK RT-HM60 SK CH 220 J 15.080
C30-1 CAPACITOR CERAMIC 22pF 5% NPO 500VDC KCK RT-HM60 SK CH 220 J 15.080
C31-4 CAPACITOR CERAMIC 22pF 5% NPO 500VDC KCK RT-HM60 SK CH 220 J 15.080
C32-4 CAPACITOR CERAMIC 15pF 5% NPO 500VDC KCK RT-HM60 SK CH 150 J 15.590
C33-4 CAPACITOR POLYSTYRENE 221pF 1% 63VDC PHILIPS 2222 443 42211 10.727
C34-4 CAPACITOR MKT 0.1uF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C35-4 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C36-4 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C37-4 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C38-4 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
0820
Page 7-18
