Sailor RT2048 VHF User Manual

7 PARTS LIST RT2048
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
0820
Page 7-19
C39-4 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C40-4 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C41-4 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C42-4 CAPACITOR CERAMIC 22pF 5% N150 500VDC KCK RT-HM SK PH 220 J 15.062
C43-4 CAPACITOR CERAMIC 51pF 5% NPO 50VDC KCK RT-HE60-SK CH 510 J 15.110
C44-4 CAPACITOR CERAMIC 6p8F +-0.5pF N150 50VDC KCK RT-HE40 SK PH 6R8 D 15.020
C45-4 CAPACITOR CERAMIC 3p9F +/-0.25pF N150 50VDC KCK RT-HE40 SK PJ 3R9 C 15.003
C46-4 CAPACITOR CERAMIC 9p1F +/-0.5pF N150 50VDC KCK RT-HE40 SK PH 9R1 D 15.033
C47-4 CAPACITOR CERAMIC 9p1F +/-0.5pF N150 50VDC KCK RT-HE40 SK PH 9R1 D 15.033
C48-4 CAPACITOR CERAMIC 9p1F +/-0.5pF N150 50VDC KCK RT-HE40 SK PH 9R1 D 15.033
C49-4 CAPACITOR CERAMIC 9p1F +/-0.5pF N150 50VDC KCK RT-HE40 SK PH 9R1 D 15.033
C50-4 CAPACITOR CERAMIC 3p3F +/-0.25pF N150 500V KCK RT-HM60 SK PJ 3R3 C 16.103
C51-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C52-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C53-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C54-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C55-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C56-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C57-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C58-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C59-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C60-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C61-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C62-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C63-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C64-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C65-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C66-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C67-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C68-4 CAPACITOR MKT 10nF 20% 100VDC PHILIPS 2222 370 38103 11.168
C69-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C70-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C71-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C72-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C73-4 CAPACITOR CERAMIC 1n0F 10% CL2 500VDC KCK RT-HM60 SK YB 102 K 15.160
C74-4 CAPACITOR CERAMIC 180pF 5% N150 50VDC KCK RT-HE95-SK PH 181 J 15.149
C75-4 CAPACITOR CERAMIC 33pF 5% N750 500VDC KCK RT-HM60 SK UJ 330 J 16.064
C76-4 CAPACITOR CERAMIC 51pF 5% NPO 50VDC KCK RT-HE60-SK CH 510 J 15.110
C77-4 CAPACITOR CERAMIC 12pF 5% N150 500VDC KCK RT-HM60 SK PH 120 J 16.114
C78-4 CAPACITOR CERAMIC 12pF 5% N150 500VDC KCK RT-HM60 SK PH 120 J 16.114
C79-4 CAPACITOR CERAMIC 18pF 5% N150 50VDC KCK RT-HE40-SK PH 180 J 15.061
C80-4 CAPACITOR MKT 1uF 10% 63VDC PHILIPS 2222 370 78105 11.137
C81-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C82-4 CAPACITOR CERAMIC 51pF 5% NPO 50VDC KCK RT-HE60-SK CH 510 J 15.110
C83-4 CAPACITOR MKT 0.1uF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C84-4 CAPACITOR CERAMIC 51pF 5% NPO 50VDC KCK RT-HE60-SK CH 510 J 15.110
C85-4 CAPACITOR CERAMIC 51pF 5% NPO 50VDC KCK RT-HE60-SK CH 510 J 15.110
C86-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C87-4 CAPACITOR CERAMIC 10pF 5% NPO 500VDC KCK RT-HM60 SK CH 100 J 15.565
C88-4 CAPACITOR CERAMIC 1nF 10% 50VDC CL2 KCK RT-SK-HE50 SJYB 102 K 16.160
C89-4 CAPACITOR CERAMIC 51pF 5% NPO 50VDC KCK RT-HE60-SK CH 510 J 15.110
D1-4 TRANSIENT SUPPRESSOR 18V 1N6277A, PFZ18A, KE1.5KE1 MOTOROLA 1N6277ARL4 26.765
D2-4 DIODE 1N4148 HIGH SPEED PHILIPS 1N4148-143 25.131
D3-4 DIODE CAPASITANCE 13pF/9VDC TOSHIBA 1SV101 in matched group 26.135
D4-4 DIODE CAPASITANCE 13pF/9VDC TOSHIBA 1SV101 in matched group 26.135
D5-4 DIODE CAPASITANCE 13pF/9VDC TOSHIBA 1SV101 in matched group 26.135
D6-4 DIODE CAPASITANCE 13pF/9VDC TOSHIBA 1SV101 in matched group 26.135
D7-4 DIODE SWITCH BA282 TFK BA 282 TAPED 25.390
F1-4 FUSE 6.3AF 250V 5x20mm LITTELFUSE 21706.3 45.571
FL1-4 CERAMIC FILTER Fc=450kHz BW=20kHz MURATA SFP 450DR 41.512
FL2-4 CRYSTAL FILTER Fc=15.3MHz NDK SP.SPEC: C1076 (15N15B) 40.029
J1-4 SOCKET 1/10" SIL 12 POLES PRECI-DIP 310-91-112 78.805
J2-4 SOCKET COAX 90 DEG. PCB VERSION TAIKO TMP-J01X-V6 78.518
J3-4 SOCKET COAX 90 DEG. PCB VERSION TAIKO TMP-J01X-V6 78.518
J4-4 ANTENNA JACK (FEMALE) SO239 KAJ V HANSEN SO239 78.504
J5-4 SOCKET COAX 90 DEG. PCB VERSION TAIKO TMP-J01X-V6 78.518
L1-4 CHOKE TL 487 T&T 6-0-25457B 400487
L2-4 CHOKE TL 487 T&T 6-0-25457B 400487
L3-4 CHOKE TL486 T&T 6-0-25456C 400486
L4-4 CHOKE 5u6H 10% FASTRON SMCC-5R6K-02 20.139
L5-4 CHOKE TL488 70nH T&T 6-0-25458 400488
L6-4 COIL RF 568nH ADJUSTABLE SUMIDA ELEC.CO. P-75B / 2175-2239-1025 38.432
L7-4 COIL TL067 T&T 6-0-20854A 400067
400067=20.053
