7 PARTS LIST RT2048
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
0820
Page 7-20
L8-4 COIL TL067 T&T 6-0-20854A 400067
400067=20.053
L9-4 COIL RF 110nH ADJUSTABLE TOKO E526HN-100117 38.409
L10-4 COIL RF 110nH ADJUSTABLE TOKO E526HN-100117 38.409
L11-4 COIL RF 110nH ADJUSTABLE TOKO E526HN-100117 38.409
L12-4 COIL RF 110nH ADJUSTABLE TOKO E526HN-100117 38.409
L13-4 COIL TL067 T&T 6-0-20854A 400067
400067=20.053
LC1-4 EMI SUPPRESSION FILTER Fo=70MHz MURATA DST310-92(91)Y5S 222M 100 18.550
LC2-4 EMI SUPPRESSION FILTER Fo=70MHz MURATA DST310-92(91)Y5S 222M 100 18.550
LC3-4 EMI SUPPRESSION FILTER Fo=70MHz MURATA DST310-92(91)Y5S 222M 100 18.550
LC4-4 EMI SUPPRESSION FILTER Fo=70MHz MURATA DST310-92(91)Y5S 222M 100 18.550
LC5-4 EMI SUPPRESSION FILTER Fo=70MHz MURATA DST310-92(91)Y5S 222M 100 18.550
LC6-4 EMI SUPPRESSION FILTER Fo=70MHz MURATA DST310-92(91)Y5S 222M 100 18.550
LC7-4 EMI SUPPRESSION FILTER Fo=70MHz MURATA DST310-92(91)Y5S 222M 100 18.550
P1-4 PLUG 6 POLES HIRSCHMANN 973 887-100 78.315
P2-4 PLUG 2x5 POLES 3M 3654-6002 / 7610-6002 JL 78.251
P3-4 PLUG 2x10 POLES 3M 3592-6002 / 7620-6002 JL 78.250
P4-4 SOCKET SUB D 9 POLES PCB VERSION 2x 4-40 NUT EDA INC. 8TO-009SS-244T(144T,344T) 78.164
P5-4 PLUG 1/10" DIL SQ.PINS 6 POLES AMP 826656-3 78.340
Q1-4 TRANSISTOR AF MED.POWER BD234-BD236-BD238 MOTOROLA BD238 (BD234,BD236) 29.070
Q2-4 TRANSISTOR BF199 PHILIPS BF199-126 28.179
Q3-4 TRANSISTOR BF199 PHILIPS BF199-126 28.179
Q4-4 TRANSISTOR BF199 PHILIPS BF199-126 28.179
Q5-4 TRANSISTOR BC557C PHILIPS BC557C-126 28.092
Q6-4 TRANSISTOR BC557C PHILIPS BC557C-126 28.092
Q7-4 TRANSISTOR BC557C * PHILIPS BC557C-126 28.092
Q8-4 TRANSISTOR N-CHAN. JFET TIS88A1 MOTOROLA TM 00 044 -1 29.735
Q9-4 TRANSISTOR N-CHAN. JFET TIS88A1 MOTOROLA TM 00 044 -1 29.735
Q10-4 TRANSISTOR MOSFET DUAL GATE N-CHAN.BF964SA TFK BF964SA 28.240
Q11-4 TRANSISTOR MOSFET DUAL GATE N-CHAN.BF964SA TFK BF964SA 28.240
Q12-4 TRANSISTOR AF NPN BC547C TO-92 PHILIPS BC547C-126 28.068
Q13-4 TRANSISTOR AF NPN BC547C TO-92 PHILIPS BC547C-126 28.068
Q14-4 TRANSISTOR DARLINGTON NPN BC618 MOTOROLA BC618 RL1 28.107
R1-4 RESISTOR MF 475 OHM 1% 0.6W PHILIPS 2322 156 14751 03.393
R2-4 RESISTOR MF 1k3 OHM 1% 0.6W PHILIPS 2322 156 11302 03.402
R3-4 RESISTOR MF 221 OHM 1% 0.6W PHILIPS 2322 156 12211 03.384
R4-4 PRESET CERMET 50 OHM 10% 0.5W BOURNS 3386P-Y91-500 07.882
R5-4 RESISTOR MF 2R7 OHM 5% 0.4W PHILIPS 2322 181 53278 01.135
R6-4 RESISTOR MF 3k92 OHM 1% 0.6W PHILIPS 2322 156 13922 03.409
R7-4 RESISTOR MF 3k92 OHM 1% 0.6W PHILIPS 2322 156 13922 03.409
R8-4 RESISTOR MF 97k6 OHM 1% 0.6W PHILIPS 2322 156 19763 03.471
R9-4 RESISTOR MF 97k6 OHM 1% 0.6W PHILIPS 2322 156 19763 03.471
R10-4 RESISTOR MF 18k OHM 5% 0.33W PHILIPS 2322 187 73183 02.502
R11-4 RESISTOR MF 43k OHM 5% 0.4W PHILIPS 2322 181 53433 01.240
R12-4 RESISTOR MF 22k OHM 5% 0.4W PHILIPS 2322 181 53223 01.233
R13-4 RESISTOR MF 2k0 OHM 5% 0.4W PHILIPS 2322 181 53202 01.207
R14-4 RESISTOR MF 1k5 OHM 5% 0.4W PHILIPS 2322 181 53152 01.204
R15-4 RESISTOR PMF 220 OHM 5% 2W PHILIPS 2322 194 13221 04.183
R16-4 RESISTOR MF 5k6 OHM 5% 0.4W PHILIPS 2322 181 53562 01.218
R17-4 RESISTOR MF 3k3 OHM 5% 0.4W PHILIPS 2322 181 53332 01.212
R18-4 RESISTOR MF 8k2 OHM 5% 0.4W PHILIPS 2322 181 53822 01.222
R19-4 PRESET CERMET 500 OHM 10% 0.5W BOURNS 3386P-Y91-501 07.885
R20-4 PRESET CERMET 50k 10% 0.5W BOURNS 3386P-Y91-503 07.892
R21-4 PRESET CERMET 2k0 OHM 5% 0.5W BOURNS 3386P-Y91-202 07.887
R22-4 RESISTOR MF 2k2 OHM 5% 0.4W PHILIPS 2322 181 53222 01.208
R23-4 RESISTOR MF 2k2 OHM 5% 0.4W PHILIPS 2322 181 53222 01.208
R24-4 RESISTOR MF 2k7 OHM 5% 0.4W PHILIPS 2322 181 53272 01.210
R25-4 RESISTOR MF 2k2 OHM 5% 0.4W PHILIPS 2322 181 53222 01.208
R26-4 RESISTOR MF 470 OHM 5% 0.4W PHILIPS 2322 181 53471 01.191
R27-4 RESISTOR MF 1k0 OHM 5% 0.4W PHILIPS 2322 181 53102 01.200
R28-4 RESISTOR MF 1k8 OHM 5% 0.4W PHILIPS 2322 181 53182 01.206
R29-4 RESISTOR MF 1k0 OHM 5% 0.4W PHILIPS 2322 181 53102 01.200
R30-4 RESISTOR MF 47k OHM 5% 0.4W PHILIPS 2322 181 53473 01.241
R31-4 RESISTOR MF 12k OHM 5% 0.4W PHILIPS 2322 181 53123 01.227
R32-4 RESISTOR MF 1k0 OHM 5% 0.4W PHILIPS 2322 181 53102 01.200
R33-4 RESISTOR MF 1k0 OHM 5% 0.4W PHILIPS 2322 181 53102 01.200
R34-4 RESISTOR MF 5k36 OHM 1% 0.6W PHILIPS 2322 156 15362 03.418
R35-4 RESISTOR MF 220k OHM 5% 0.4W PHILIPS 2322 181 53224 01.258
R36-4 RESISTOR MF 3k9 OHM 5% 0.33W PHILIPS 2322 187 73392 02.486
R37-4 RESISTOR MF 3k9 OHM 5% 0.4W PHILIPS 2322 181 53392 01.214
R38-4 RESISTOR MF 3k9 OHM 5% 0.4W PHILIPS 2322 181 53392 01.214
R39-4 RESISTOR MF 3k9 OHM 5% 0.33W PHILIPS 2322 187 73392 02.486
