7 PARTS LIST RT2048
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
0820
Page 7-21
R40-4 RESISTOR MF 560 OHM 5% 0.4W PHILIPS 2322 181 53561 01.193
R41-4 RESISTOR MF 180 OHM 5% 0.4W PHILIPS 2322 181 53181 01.181
R42-4 RESISTOR MF 120k OHM 5% 0.4W PHILIPS 2322 181 53124 01.252
R43-4 RESISTOR MF 100k OHM 5% 0.4W PHILIPS 2322 181 53104 01.250
R44-4 RESISTOR MF 100k OHM 5% 0.4W PHILIPS 2322 181 53104 01.250
R45-4 RESISTOR MF 100k OHM 5% 0.4W PHILIPS 2322 181 53104 01.250
R46-4 RESISTOR MF 470k OHM 5% 0.4W PHILIPS 2322 181 53474 01.266
R47-4 RESISTOR MF 56k OHM 5% 0.33W PHILIPS 2322 187 73563 02.514
R48-4 RESISTOR MF 100k OHM 5% 0.4W PHILIPS 2322 181 53104 01.250
R49-4 RESISTOR MF 330 OHM 5% 0.4W PHILIPS 2322 181 53331 01.187
R50-4 RESISTOR MF 330 OHM 5% 0.4W PHILIPS 2322 181 53331 01.187
R51-4 RESISTOR MF 39k OHM 5% 0.4W PHILIPS 2322 181 53393 01.239
R52-4 RESISTOR MF 39k OHM 5% 0.4W PHILIPS 2322 181 53393 01.239
R53-4 RESISTOR MF 39k OHM 5% 0.4W PHILIPS 2322 181 53393 01.239
R54-4 RESISTOR MF 39k OHM 5% 0.4W PHILIPS 2322 181 53393 01.239
R55-4 RESISTOR MF 120k OHM 5% 0.33W PHILIPS 2322 187 73124 02.522
R56-4 RESISTOR MF 15k OHM 5% 0.4W PHILIPS 2322 181 53153 01.229
R57-4 RESISTOR MF 15k OHM 5% 0.33W PHILIPS 2322 187 73153 02.500
R58-4 RESISTOR MF 27k OHM 5% 0.4W PHILIPS 2322 181 53273 01.235
R59-4 RESISTOR MF 27k OHM 5% 0.4W PHILIPS 2322 181 53273 01.235
R60-4 RESISTOR MF 27k OHM 5% 0.4W PHILIPS 2322 181 53273 01.235
R61-4 RESISTOR MF 27k OHM 5% 0.4W PHILIPS 2322 181 53273 01.235
R62-4 RESISTOR MF 27k OHM 5% 0.4W PHILIPS 2322 181 53273 01.235
R63-4 RESISTOR MF 27k OHM 5% 0.4W PHILIPS 2322 181 53273 01.235
R64-4 RESISTOR MF 27k OHM 5% 0.4W PHILIPS 2322 181 53273 01.235
R65-4 RESISTOR MF 27k OHM 5% 0.4W PHILIPS 2322 181 53273 01.235
R66-4 RESISTOR MF 68k OHM 5% 0.4W PHILIPS 2322 181 53683 01.245
R67-4 RESISTOR MF 56k OHM 5% 0.33W PHILIPS 2322 187 73563 02.514
RE1-4 RELAY 12VDC 2SH 1.25A MEISEI M1B-12-H 21.030
TR1-4 TRAFO RF 2u7H ADJUSTABLE TOKO F292MNS-3342BQE 38.431
TR2-4 TRAFO 157MHz ADJUSTABLE SUMIDA ELEC.CO. S-7GD / 0237-1756 38.430
U1-4 POS. VOLTAGE REG. ADJUST. Io=1.5A LM317T MOTOROLA LM317T 31.055
U2-4 AF POWER AMPLIFIER TDA1515A PHILIPS TDA1515A 31.489
U3-4 NBFM IF SYSTEM MC3361 PHILIPS MC 3361 N 31.325
U4-4 VHF POWER AMP. 25W S-AV6/M57710A/MC5233 MITSUBISHI M57710-A 32.450
RX/TX MODULE RT2048 T&T 93-127059-B 60-127059
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
VARIOUS SHUNT CONNECTOR FEMALE 2 POLES AMP 142270-1 78.325
VARIOUS FUSECLIP FOR 20x5mm FUSELINK KEYSTONE CAT.NO.3521 78.396
C1-4 CAPACITOR CERAMIC 2p7F +/-0.25pF NPO 100VDC PHILIPS 2222 689 09278 15.320
C2-4 CAPACITOR ELECTROLYTIC 1000uF 20% 35VDC SAMHWA ELEC. SV-1000uF-35WV 14.655
C3-4 CAPACITOR MKT 0.1uF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C4-4 CAPACITOR ELECTROLYTIC 4.7uF 20% 50VDC ELNA RJ2-50-V-4R7-M-T58 14.510
C5-4 CAPACITOR ELECTROLYTIC 22uF 20% 25VDC ELNA RJ2-25-V-220-M-T58 14.514
C6-4 CAPACITOR ELECTROLYTIC 22uF 20% 25VDC ELNA RJ2-25-V-220-M-T58 14.514
C7-4 CAPACITOR ELECTROLYTIC 33uF 20% 16VDC ELNA RJ2-16-V-330-M-T58 14.518
C8-4 CAPACITOR ELECTROLYTIC 33uF 20% 16VDC ELNA RJ2-16-V-330-M-T58 14.518
C9-4 CAPACITOR ELECTROLYTIC 33uF 20% 16VDC ELNA RJ2-16-V-330-M-T58 14.518
C10-4 CAPACITOR ELECTROLYTIC 33uF 20% 16VDC ELNA RJ2-16-V-330-M-T58 14.518
C11-4 CAPACITOR MKT 0.1uF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
R12-4 CAPACITOR MKT 0.1uF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C13-4 CAPACITOR CERAMIC 10pF 5% NPO 500VDC KCK RT-HM60 SK CH 100 J 15.565
C14-4 CAPACITOR CERAMIC 10pF 5% NPO 500VDC KCK RT-HM60 SK CH 100 J 15.565
C15-4 CAPACITOR CERAMIC 18pF 5% NPO 500VDC KCK RT-HM60 SK CH 180 J 15.060
C16-4 CAPACITOR CERAMIC 18pF 5% NPO 500VDC KCK RT-HM60 SK CH 180 J 15.060
C17-4 CAPACITOR ELECTROLYTIC 10uF 20% 35VDC ELNA RJ2-35-V-100-M-T58 14.512
C18-4 CAPACITOR ELECTROLYTIC 1uF 20% 50VDC ELNA RJ2-50-V-010-M-T34 14.506
C19-4 CAPACITOR MKT 0.1uF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C20-4 CAPACITOR MKT 0.1uF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C21-4 CAPACITOR MKT 0.1uF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C22-4 CAPACITOR MKT 0.1uF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C23-4 CAPACITOR MKT 0.1uF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C24-4 CAPACITOR MKT 0.1uF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C25-4 CAPACITOR CERAMIC 51pF 5% NPO 50VDC KCK RT-HE60-SK CH 510 J 15.110
C26-4 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C27-4 CAPACITOR CERAMIC 51pF 5% NPO 50VDC KCK RT-HE60-SK CH 510 J 15.110
C28-4 CAPACITOR CERAMIC 51pF 5% NPO 50VDC KCK RT-HE60-SK CH 510 J 15.110
C29-4 CAPACITOR CERAMIC 22pF 5% NPO 500VDC KCK RT-HM60 SK CH 220 J 15.080
