7 PARTS LIST RT2048
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
R35-4 RESISTOR MF 220k OHM 5% 0.4W PHILIPS 2322 181 53224 01.258
R36-4 RESISTOR MF 3k9 OHM 5% 0.33W PHILIPS 2322 187 73392 02.486
R37-4 RESISTOR MF 3k9 OHM 5% 0.4W PHILIPS 2322 181 53392 01.214
R38-4 RESISTOR MF 3k9 OHM 5% 0.4W PHILIPS 2322 181 53392 01.214
R39-4 RESISTOR MF 3k9 OHM 5% 0.33W PHILIPS 2322 187 73392 02.486
R40-4 RESISTOR MF 560 OHM 5% 0.4W PHILIPS 2322 181 53561 01.193
R41-4 RESISTOR MF 180 OHM 5% 0.4W PHILIPS 2322 181 53181 01.181
R42-4 RESISTOR MF 120k OHM 5% 0.4W PHILIPS 2322 181 53124 01.252
R43-4 RESISTOR MF 100k OHM 5% 0.4W PHILIPS 2322 181 53104 01.250
R44-4 RESISTOR MF 100k OHM 5% 0.4W PHILIPS 2322 181 53104 01.250
R45-4 RESISTOR MF 100k OHM 5% 0.4W PHILIPS 2322 181 53104 01.250
R46-4 RESISTOR MF 470k OHM 5% 0.4W PHILIPS 2322 181 53474 01.266
R47-4 RESISTOR MF 56k OHM 5% 0.33W PHILIPS 2322 187 73563 02.514
R48-4 RESISTOR MF 100k OHM 5% 0.4W PHILIPS 2322 181 53104 01.250
R49-4 RESISTOR MF 330 OHM 5% 0.4W PHILIPS 2322 181 53331 01.187
R50-4 RESISTOR MF 330 OHM 5% 0.4W PHILIPS 2322 181 53331 01.187
R51-4 RESISTOR MF 39k OHM 5% 0.4W PHILIPS 2322 181 53393 01.239
R52-4 RESISTOR MF 39k OHM 5% 0.4W PHILIPS 2322 181 53393 01.239
R53-4 RESISTOR MF 39k OHM 5% 0.4W PHILIPS 2322 181 53393 01.239
R54-4 RESISTOR MF 39k OHM 5% 0.4W PHILIPS 2322 181 53393 01.239
R55-4 RESISTOR MF 120k OHM 5% 0.33W PHILIPS 2322 187 73124 02.522
R56-4 RESISTOR MF 15k OHM 5% 0.4W PHILIPS 2322 181 53153 01.229
R57-4 RESISTOR MF 15k OHM 5% 0.33W PHILIPS 2322 187 73153 02.500
R58-4 RESISTOR MF 27k OHM 5% 0.4W PHILIPS 2322 181 53273 01.235
R59-4 RESISTOR MF 27k OHM 5% 0.4W PHILIPS 2322 181 53273 01.235
R60-4 RESISTOR MF 27k OHM 5% 0.4W PHILIPS 2322 181 53273 01.235
R61-4 RESISTOR MF 27k OHM 5% 0.4W PHILIPS 2322 181 53273 01.235
R62-4 RESISTOR MF 27k OHM 5% 0.4W PHILIPS 2322 181 53273 01.235
R63-4 RESISTOR MF 27k OHM 5% 0.4W PHILIPS 2322 181 53273 01.235
R64-4 RESISTOR MF 27k OHM 5% 0.4W PHILIPS 2322 181 53273 01.235
R65-4 RESISTOR MF 27k OHM 5% 0.4W PHILIPS 2322 181 53273 01.235
R66-4 RESISTOR MF 68k OHM 5% 0.4W PHILIPS 2322 181 53683 01.245
R67-4 RESISTOR MF 56k OHM 5% 0.33W PHILIPS 2322 187 73563 02.514
R68-4 RESISTOR 0 OHM PHILIPS 2322 181 90018 01.110
R69-4 RESISTOR MF 1k0 OHM 5% 0.4W PHILIPS 2322 181 53102 01.200
R70-4 RESISTOR MF 2k2 OHM 5% 0.4W PHILIPS 2322 181 53222 01.208
RE1-4 RELAY 12VDC 2SH 1.25A MEISEI M1B-12-H 21.030
TR1-4 TRAFO RF 2u7H ADJUSTABLE TOKO F292MNS-3342BQE 38.431
TR2-4 TRAFO 157MHz ADJUSTABLE SUMIDA ELEC.CO. S-7GD / 0237-1756 38.430
U1-4 POS. VOLTAGE REG. ADJUST. Io=1.5A LM317T MOTOROLA LM317T 31.055
U2-4 AF POWER AMPLIFIER TDA1515A PHILIPS TDA1515A 31.489
U3-4 NBFM IF SYSTEM MC3361 PHILIPS MC 3361 N 31.325
U4-4 POWER MODULE VHF 40W/12.5VDC RA35H1516M-01 MITSUBISHI RA35H1516M-01 32.459
SELCALL MODULE (OPTIONAL) RT2048 T&T 5-0-25449B / 4-0-25449D 625449
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
C1-5 CAPACITOR KP 10nF 2.5% 63VDC EVOX PFR 103H TA18 13.407
C2-5 CAPACITOR KP 10nF 2.5% 63VDC EVOX PFR 103H TA18 13.407
C3-5 CAPACITOR KP 3.9nF 2.5% 63VDC EVOX PFR 392H TA18 13.402
C4-5 CAPACITOR KP 3.9nF 2.5% 63VDC EVOX PFR 392H TA18 13.402
C5-5 CAPACITOR MKT 22nF 10% 100VDC PHILIPS 2222 370 88223 11.175
C6-5 CAPACITOR MKT 150nF 5% 50VDC ERO MKT 1826-415/06 4-G 11.181
C7-5 CAPACITOR MKT 47nF 10% 63VDC EVOX MMK5 473K63 TA18 11.644
C8-5 CAPACITOR MKT 47nF 10% 63VDC EVOX MMK5 473K63 TA18 11.644
C9-5 CAPACITOR MKT 47nF 10% 63VDC EVOX MMK5 473K63 TA18 11.644
C10-5 CAPACITOR MKT 47nF 10% 63VDC EVOX MMK5 473K63 TA18 11.644
C11-5 CAPACITOR MKT 47nF 10% 63VDC EVOX MMK5 473K63 TA18 11.644
C12-5 CAPACITOR MKT 47nF 10% 63VDC EVOX MMK5 473K63 TA18 11.644
C13-5 CAPACITOR MKT 47nF 10% 63VDC EVOX MMK5 473K63 TA18 11.644
C14-5 CAPACITOR MKT 47nF 10% 63VDC EVOX MMK5 473K63 TA18 11.644
D1-5 DIODE SCHOTTKY BAT 43 THOMSON-CSF BAT43 27.600
D2-5 DIODE SCHOTTKY BAT 43 THOMSON-CSF BAT43 27.600
J1-5 SOCKET COAX FOR PCB 45 DEG. HORIZONTAL TAIKO TMP-J01X-A2 78.517
J2-5 SOCKET 7 POLES F.RIBBON CABLE MOLEX 52011-0710 78.280
Q1-5 TRANSISTOR RF SWITCH 2N2369A MOTOROLA 2N2369A 28.315
R1-5 PRESET CERMET 2k0 OHM 5% 0.5W BOURNS 3386P-1-202-11 07.887
R2-5 RESISTOR MF 6k49 OHM 1% 0.6W PHILIPS 2322 156 16492 03.412
R3-5 RESISTOR MF 243 OHM 1% 0.6W PHILIPS 2322 156 12431 03.385
R4-5 RESISTOR MF 7k50 OHM 1% 0.6W PHILIPS 2322 156 17502 03.448
0820
Page 7-24
