Sailor RT2048 VHF User Manual

7 PARTS LIST RT2048
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
R5-5 RESISTOR MF 7k50 OHM 1% 0.6W PHILIPS 2322 156 17502 03.448
R6-5 RESISTOR MF 10k OHM 5% 0.4W PHILIPS 2322 181 53103 01.225
R7-5 RESISTOR MF 10k OHM 5% 0.4W PHILIPS 2322 181 53103 01.225
R8-5 RESISTOR MF 10k OHM 5% 0.4W PHILIPS 2322 181 53103 01.225
R9-5 RESISTOR MF 10k OHM 5% 0.4W PHILIPS 2322 181 53103 01.225
R10-5 RESISTOR MF 12k OHM 5% 0.4W PHILIPS 2322 181 53123 01.227
R11-5 RESISTOR MF 330 OHM 5% 0.4W PHILIPS 2322 181 53331 01.187
R12-5 RESISTOR MF 680k OHM 5% 0.4W PHILIPS 2322 181 53684 01.270
R13-5 RESISTOR MF 330k OHM 5% 0.4W PHILIPS 2322 181 53334 01.262
R14-5 RESISTOR MF 453k OHM 1% 0.6W PHILIPS 2322 156 14534 03.516
R15-5 RESISTOR MF 7k50 OHM 1% 0.6W PHILIPS 2322 156 17502 03.448
R16-5 RESISTOR MF 390k OHM 5% 0.4W PHILIPS 2322 181 53394 01.264
R17-5 RESISTOR MF 390k OHM 5% 0.4W PHILIPS 2322 181 53394 01.264
R18-5 RESISTOR MF 20k0 OHM 1% 0.6W PHILIPS 2322 156 12003 03.452
R19-5 RESISTOR MF 61k9 OHM 1% 0.6W PHILIPS 2322 156 16193 03.239
R20-5 RESISTOR MF 4k7 OHM 5% 0.4W PHILIPS 2322 181 53472 01.216
R21-5 RESISTOR MF 10k OHM 5% 0.4W PHILIPS 2322 181 53103 01.225
R22-5 RESISTOR MF 3kO OHM 5% 0.4W PHILIPS 2322 181 53302 01.211
R23-5 RESISTOR MF 12k OHM 5% 0.4W PHILIPS 2322 181 53123 01.227
R24-5 RESISTOR MF 2k2 OHM 5% 0.4W PHILIPS 2322 181 53222 01.208
R25-5 RESISTOR MF 7k50 OHM 1% 0.6W PHILIPS 2322 156 17502 03.448
U1-5 INTEGRATED CIRCUIT LF347N NATIOPNAL LF347N 31.530
U2-5 QUAD ANALOG SWITCH MC14066B/CD4066B MOTOROLA MC14066BCP 33.232
U3-5 DUAL TYPE D FLIP-FLOP MC14013BCP MOTOROLA MC14013BCP 33.056
U4-5 DUAL OP AMP LM358N TEXAS LM358P 31.100
U5-5 POS. VOLTAGE REG. FIXED 5V 5% 0.1A 78L05AC MOTOROLA MC78L05ACP 31.135
U6-5 INTEGRATED CIRCUIT MC14569BCP MOTOROLA MC14569BCP 33.449
U7-5 INTEGRATED CIRCUIT MC14094BCP MOTOROLA MC14094BCP 33.305
U8-5 IC CMOS HEX LEVEL SHIFTER MOTOROLA MC 14504 BCP 33.282
SELCALL ALARM (MODULE 6) SPECIAL OPTION FOR RT2048 T&T 4-0-25660 / 5-0-25473 625660
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
D1 DIODE HIGH SPEED 1N4448 PHILIPS 1N4448 25.147
P1 PLUG 1/10" SIL 12 POLES EURO DIP SL 12 O Z 78.328
Q1 TRANSISTOR DARLINGTON NPN BC618 MOTOROLA BC618 28.107
R1/4 RESISTOR ARRAY 4x10k OHM 5% 1/8W PANASONIC EXBF8V103G (4X10K) 08.615
RE1 RELAY 12VDC 1SH. 2A. ORIGINAL ELEC. OUC-SS-112D (-S-/-SH-) 21.300
RE2 RELAY 12VDC 1SH. 2A. ORIGINAL ELEC. OUC-SS-112D (-S-/-SH-) 21.300
DISTRESS OUTPUT(MODULE 6) SPECIAL OPTION FOR RT2048 T&T 4-0-25661 / 5-0-25473 625661
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
D3 DIODE HIGH SPEED 1N4448 PHILIPS 1N4448 25.147
P1 PLUG 1/10" SIL 12 POLES EURO DIP SL 12 O Z 78.328
Q3 TRANSISTOR BC638 MOTOROLA* BC638 / BC640 28.117
Q4 TRANSISTOR DARLINGTON NPN BC618 MOTOROLA BC618 28.107
R1/4 RESISTOR ARRAY 4x10k OHM 5% 1/8W PANASONIC EXBF8V103G (4X10K) 08.615
R2/4 RESISTOR ARRAY 4x10k OHM 5% 1/8W PANASONIC EXBF8V103G (4X10K) 08.615
R2/2 RESISTOR ARRAY 4x10k OHM 5% 1/8W PANASONIC EXBF8V103G (4X10K) 08.615
R2/3 RESISTOR ARRAY 4x10k OHM 5% 1/8W PANASONIC EXBF8V103G (4X10K) 08.615
R3 RESISTOR MF 1k0 OHM 5% 0.4W PHILIPS 2322 181 53102 01.200
R4 RESISTOR MF 1k0 OHM 5% 0.4W PHILIPS 2322 181 53102 01.200
AUX INTERFACE (MODULE 6) SPECIAL OPTION FOR RT2048 T&T 5-0-25473 625473
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
D1 DIODE HIGH SPEED 1N4448 PHILIPS 1N4448 25.147
D2 DIODE HIGH SPEED 1N4448 PHILIPS 1N4448 25.147
D3 DIODE HIGH SPEED 1N4448 PHILIPS 1N4448 25.147
P1 PLUG 1/10" SIL 12 POLES EURO DIP SL 12 O Z 78.328
Q1 TRANSISTOR DARLINGTON NPN BC618 MOTOROLA BC618 28.107
Q2 TRANSISTOR DARLINGTON NPN BC618 MOTOROLA BC618 28.107
Q3 TRANSISTOR BC638 MOTOROLA* BC638 / BC640 28.117
0820
Page 7-25
