Sailor RT2048 VHF User Manual

7 PARTS LIST RT2048
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
Q4 TRANSISTOR DARLINGTON NPN BC618 MOTOROLA BC618 28.107
R1/4 RESISTOR ARRAY 4x10k OHM 5% 1/8W PANASONIC EXBF8V103G (4X10K) 08.615
R2/4 RESISTOR ARRAY 4x10k OHM 5% 1/8W PANASONIC EXBF8V103G (4X10K) 08.615
R3 RESISTOR MF 1k0 OHM 5% 0.4W PHILIPS 2322 181 53102 01.200
R4 RESISTOR MF 1k0 OHM 5% 0.4W PHILIPS 2322 181 53102 01.200
RE1 RELAY 12VDC 1SH. 2A. ORIGINAL ELEC. OUC-SS-112D (-S-/-SH-) 21.300
RE2 RELAY 12VDC 1SH. 2A. ORIGINAL ELEC. OUC-SS-112D (-S-/-SH-) 21.300
RE3 RELAY 12VDC 1SH. 2A. ORIGINAL ELEC. OUC-SS-112D (-S-/-SH-) 21.300
RE4 RELAY 12VDC 1SH. 2A. ORIGINAL ELEC. OUC-SS-112D (-S-/-SH-) 21.300
U1 OPTO COUPLER CNY17-3 MOTOROLA CNY17-3 32.533
BUS-INTERRUPT OPTION (6) RM2042 T&T 5-0-26945B / 4-0-26945 626945
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
C1-6 CAPACITOR CERAMIC 1nOF 10% CL2 500VDC KCK RT-HM60 SK YB 102 K 15.160
P1-6 PLUG 1/10" SIL 12 POLES EURO DIP SL 12 O Z 78.328
Q1-6 TRANSISTOR AF NPN BC547C TO-92 PHILIPS BC547C 28.068
R1-6 RESISTOR MF 10k OHM 5% 0.4W PHILIPS 2322 181 53103 01.225
R2-6 RESISTOR MF 10k OHM 5% 0.4W PHILIPS 2322 181 53103 01.225
ATIS BASE MODULE FOR RT2048 (6) T&T 5-0-28652A / 4-0-28652B 628652
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
VARIOUS SHIELD FOR BASE PCB RT2048 T&T 1-0-26448A 226448
C1-6 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C2-6 CAPACITOR TANTALUM 3528 2u2F 20% 16VDC ERO CB 225020 M E17 334.028
C3-6 CAPACITOR CERAM. SMD 0805 10nF 10% X7R 50VDC MURATA GRM40 X7R 103 K 50 PT 328.336
C4-6 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C5-6 CAPACITOR CERAM. SMD 0805 10nF 10% X7R 50VDC MURATA GRM40 X7R 103 K 50 PT 328.336
C6-6 CAPACITOR CERAM. SMD 1206 3n9 5% NPO 50VDC MURATA GRM42-6COG392J 50PT10 324.105
C7-6 CAPACITOR CERAM. SMD 1206 3n9 5% NPO 50VDC MURATA GRM42-6COG392J 50PT10 324.105
C8-6 CAPACITOR CERAM. SMD 0805 10nF 10% X7R 50VDC MURATA GRM40 X7R 103 K 50 PT 328.336
C9-6 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C10-6 CAPACITOR TANTALUM 3528 2u2F 20% 16VDC ERO CB 225020 M E17 334.028
D1-6 DIODE BAS32L PHILIPS BAS32L 340.032
D2-6 DIODE BAS32L PHILIPS BAS32L 340.032
D3-6 DIODE BAS32L PHILIPS BAS32L 340.032
D4-6 DIODE BAS32L PHILIPS BAS32L 340.032
D5-6 DIODE BAS32L PHILIPS BAS32L 340.032
D6-6 DIODE BAS32L PHILIPS BAS32L 340.032
J1-6 SOCKET 2x6 POLES 1/20" PCB VERSION AMP 4-175638-2 376.065
P1-6 PLUG 1/10" SIL 12 POLES EURO DIP SL 12 O Z 78.328
Q1-6 TRANSISTOR AF SMALL SIGN SOT23 BC848B PHILIPS BC848B 7-INCH/LARGE REEL 345.048
ID: 1Kp
Q2-6 TRANSISTOR AF SMALL SIGN SOT23 BC848B PHILIPS BC848B 7-INCH/LARGE REEL 345.048
ID: 1Kp
R1-6 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 JZO J 103 E 302.060
R2-6 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 JZO J 103 E 302.060
R3-6 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 JZO J 103 E 302.060
R4-6 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 JZO J 104 E 302.072
R5-6 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 JZO J 103 E 302.060
R6-6 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 JZO J 103 E 302.060
R7-6 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 JZO J 103 E 302.060
R8-6 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 JZO J 103 E 302.060
R9-6 RESISTOR SMD 0805 6k8 OHM 5% 0.1W ROHM MCR 10 JZO J 682 E 302.058
R10-6 RESISTOR SMD 0805 6k8 OHM 5% 0.1W ROHM MCR 10 JZO J 682 E 302.058
R11-6 RESISTOR SMD 0805 39k OHM 5% 0.1W ROHM MCR 10 JZO J 393 E 302.067
R12-6 RESISTOR SMD 0805 68k OHM 5% 0.1W ROHM MCR 10 JZO J 683 E 302.070
R13-6 RESISTOR SMD 0805 82k OHM 5% 0.1W ROHM MCR 10 JZO J 823 E 302.071
R14-6 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 JZO J 104 E 302.072
R15-6 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 JZO J 104 E 302.072
R16-6 RESISTOR SMD 0805 1k0 OHM 5% 0.1W ROHM MCR 10 JZO J 102 E 302.048
R17-6 RESISTOR MF 10 OHM 5% 0.4W PHILIPS 2322 181 53109 01.150
RE1-6 RELAY 12VDC 1SH. 2A. ORIGINAL ELEC. OUC-SS-112D (-S-/-SH-) 21.300
U1-6 VOLTAGE REGULATOR 5V/0.1A 78L05A MOTOROLA MC78L05ACD 350.100
U2-6 INTEGRATED CIRCUIT 74HC14D TEXAS* SN74HC14D 355.213
R3-6 DUAL LOW POW. OP AMP LM358 NATIONAL LM358M (LM358AM) 350.525
0820
Page 7-26
