6
Basic
When releasing the replay button the replay function will take over the audio system and
start to replay the last XX seconds of data received on any channel. The time when the traffic
was received and the channel on which it was received is displayed during replay.
Volume control can be used on the replay data to adjust sound pressure in audio devices.
During replay “— —” is shown in the channel display, to indicate that listening on the live
receive signal is disabled in this situation (as well as recording is disabled). If a signal is
received on the working channel while replay is activated, this is indicated in the lower left
corner of the replay window.
Replay is interrupted when:
• Pressing , or
• Pressing PTT
• Receiving any message in the information/message display
Recorded voice data will not survive power-down of any kind
.
1.11 Dimming
To adjust the light intensity the dim button is pressed.
While the dim button is pressed the intensity is changing. Releasing the dim
button will maintain the current light intensity.
A renewed pressing of the dim button will change the direction of the light intensity change.
If the VHF is dimmed to zero, any key press will wake up the light to a minimum visible at
night. Active text in the information/message display might prevent dimming to zero.
It is possible to reduce illumination to zero. If you press a key in this state the light will
illuminate to the lowest illuminated state for 5 seconds, where after it will return to the zero
illumination state. If a message is shown on the screen while dimming is set to zero, the
illumination is adjusted to the lowest nonzero value.
1.12 Contrast
Contrast of the information/message display (and thereby optimizing the vertical viewing
angle) can be adjusted initially by entering the Display Contrast menu. Use the arrows to
adjust contrast. The contrast will be set simultaneously during adjustment.
0544
