Sailor RT5020 VHF DSC Duplex - Installation Guide (continued); Flush Mounting and Drilling Plans

42
Installation
Mounting option Drilling plan
39836
Tilting +/- 20°
39837
16 190
222
5
70
80
4xø5.5
Weight (RT5022):
VHF 4.1 kg
Mounting bracket 1.0 kg
Weight (RT5020):
VHF 4.9 kg
Mounting bracket 1.0 kg
VHF with flush mounting bracket
39938
Bracket (Option)
Space for Cable entry
min. 100.00
240
120
3
Drilling plan
39945
228
10
219
9
102
6
108
6
2020
20 20
4 pcs. ø5
4 pcs. ø3.5
countersunk for M3
Weight:
Mounting kit
(Part no. 739814) 1 kg
WARNING:
Only use screws supplied with mounting
kit for attaching flush mounting bracket to
VHF radio.
0833
