Weight/Thickness Conversion for LeatherWorkhorse
®
Servo Motor Error Codes
ERROR CODE (WILL SHOW
ON LED DISPLAY)
SOLUTION
“E1”: Operational failure
Machine is locked� Check to see if the machine
isdifculttoturnbyhandwiththePowerPlus
®
Flywheel.Removematerialandattempttooperate;
if it works, material was too heavy for motor�
“E2”: Over current or under voltage
Check the power source to ensure that the motor
voltage matches the outlet voltage�
“E3”: Board cannot read the parameter
Turn the power off and on twice, and try again� If the
problem still occurs, contact Sailrite�
“E4”: Hall signal error
Replace the main fuse� To do this, turn off and
unplug the motor, remove the front external plastic
cover and replace the main fuse with one of the
extras sent with the motor� If the problem continues
to persist, please contact Sailrite
®
�
“E5”: Needle position problem
1� Press and release the “S” button and the LED
display will change to “P�”
2� Press the “P” button 2 times and the display will
change to “n1�”
3� Press the “S” button and the display will change
to “1�”
4� Press the “S” button again and the display will
change to “0” (disable needle positioner)�
5� Press the “P” button to save the value�
6� Turn the power off and then on again to complete
the programming�
OUNCES IRONS INCHES MILLIMETERS
1 0�75 1/64 0�4
2 1�5 1/32 0�8
3 2�25 3/64 1�2
4 3�00 1/16 1�6
5 3�75 5/64 2�0
6 4�50 3/32 2�4
7 5�25 7/64 2�8
8 6�00 1/8 3�2
9 6�75 9/64 3�6
10 7�50 5/32 4�0
11 8�25 11/64 4�4
12 9�00 3/16 4�8
13 9�75 13/64 5�2
14 10�50 7/32 5�6
15 11�25 15/64 6�0
16 12�00 1/4 6�4
