Leatherwork Specifications
Max� Sewing Speed Stitch-by-Stitch up to 412 stitches/minute
Shuttle Oscillating (Cam/Rocker Arm Driven)
Max� Straight Stitch Length 6mm
Needle Bar Stroke 34mm
Needle System 135 x 17, 135 x 16
Bed Size 14.5"x7"
Underarm Space 7"x4.5"
Presser Foot Lift 3/8"(0.375")
Bobbin Size Class 15/Style A (20�5mm Dia� x 10�8mm H)
Needle Size Range #10-22
Thread Range Home Sizes to V-92 (T-90)
Workhorse
®
Servo Motor Specifications
Voltage
110-120Vor220-240V(checkmotortoconrm
voltage)
H�P� 0�75
Power 550W
Power Consumption 4�5 amps
Motor RPM 4,500
Speed Control Digital
Sailrite Pulley (Cogged)
Pulley Type 21-Tooth Timing Pulley
Pulley Diameter 1.3125"(33.3375mm)
On-Off Switch Built-in
Motor Dimensions (Bracket Included) 9.75"Lx9"Hx6"W
