80
Lane change signals
To change lane to left or right,
push gently the lamps control
lever in the desired direction.
After releasing the lever, it will
return to its initial position.
Green arrows on the instrument
panel indicate which turn signal
lamps are ON. If these arrow
lights stay on or off continuously
or blink abnormally, it is possible
that one or both turn signal
lamps are burned-out and they
must be replaced.
Headlamps brightness
adjuster thumbwheel
This vehicle has a headlamps
brightness adjuster thumbwheel
which sets the brightness in a
desired level not to block the
vision of the opposite vehicles
drivers.
How to set the headlamps
brightness
The headlamps brightness
adjuster thumbwheel can be set
based on the vehicle loading in
four different positions.
Head brightness adjustment
vehicle loadposition
TrunkRear seatsFront seats
--
One or two persons
-
Three personsTwo persons
kg 35Three personsTwo persons
2
Max. load
-
One person
3
0
0
OWM084
4
Lamps
