SAJ H2-10K-T2 User Manual

Hybrid Solar Inverter User Manual
7
8
M6*50 screw *4
Plastic expansion tube *4
Gasket *4
Communication module *1
Smart meter *1
Current transformer *3
M5*12 screw *2
120Ω resistor *1
PV cover
M4*10 screw *4
Protective cover*2
Screw*4
Documents
2.3. Dimension
2.4. Datasheet
H2-(5K, 6K, 8K, 10K)-T2
MODEL
H2-5K-T2
H2-6K-T2
H2-8K-T2
H2-10K-T2
PV String Input
Max. PV Array Power [Wp]@STC
7500
9000
12000
15000
Max. DC Voltage [V]
1000
MPPT Voltage Range [V]
180 – 900
Nominal DC Voltage [V]
600
Start Voltage [V]
180
Max. DC Input Current [A]
15 / 15
Max. DC Short Circuit Current [A]
18 / 18
No. of MPPT
2
No. of Strings per MPPT
1/1
Battery Input
Battery Type
Lithium battery
Voltage Range [V]
180 – 600
Max. Charging/ Discharging Current [A]
30/30
Rated Charging/ Discharging Power [W]
5000
6000
8000
10000
AC Output /Input Data (On-grid)
Rated AC Power [W]
5000
6000
8000
10000
Rated Apparent Power [rVA]
5000
6000
8000
10000
Max. Apparent Power [VA]
5500
6600
8800
11000
Rated /Max. AC Current Output to
Utility Grid [A]
8.3
10.0
13.3
16.7
Max. AC Current from Utility Grid [A]
14.5
17.4
23.2
29.0
Current Inrush[A]
52
Max. AC Fault Current[A]
45
Max. AC Over Current Protection[A]
20.8
25
33.3
41.8
Nominal AC Voltage [V]
220/ 380 V AC, 230/ 400 V AC, 3/ N/ PE
Rated Grid Frequency / Range [Hz]
50/ 60 ± 5
Power Factor [cos φ]
0.8 leading – 0.8 lagging
Total Harmonic Distortion [THDi]
<3%
AC Output [Back-up Mode]
Max. Output Power [VA]
5000
6000
8000
10000
Max. Output Current [A]
8.0
9.6
12.8
15.9
Rated Output Voltage [V]
220/ 380 V AC, 230/ 400 V AC, 3/ N/ PE
Rated Output Frequency [Hz]
50/ 60 ± 5
