SAJ PDS33-2S2R2 User Manual

PDS33 Series
- 34 -
Function
Code
Function
Description
Unit
Factory
setting
Modification
Type
Communicati
on Address
FC.02
Data bit check
0：(8.N.2)no check
1：(8.E.1) even check
2：(8.O.1) odd check
3：(8.N.1) no check
1
3
○
FC02
FC.03
Communicatio
n response
delay time
0ms ～ 20ms
1ms
2
○
FC03
FC.04
Communicatio
n timeout fault
time
0.0（invalid），0.1s~60.0s
0.1s
0
○
FC04
FC.05
Current
resolution of
communicatio
n
0：0.01A
1：0.1A
1
0
○
FC05
FD Group：Special parameters for solar pump controller
FD.00
Solar pump
controller
function
0：Disabled
1：Enabled
1
1
○
FD00
FD.01
Source of
MPPT set
0：Keypad
1：MPPT Tracing
1
1
○
FD01
FD.02
MPPT voltage
keypad setting
FD.14 ～FD.15
0.1V
530.0V
○
FD02
FD.03
Weak light
detect time
0.0s ～ 1000.0s
0.1s
100.0s
○
FD03
FD.04
Weak light
restart time
0.0s ～ 3600.0s
0.1s
300.0s
○
FD04
FD.05
MPPT voltage
default value
70.0% ～100.0%
0.1%
80.0%
○
FD05
FD.06
PV Open
circuit voltage
250.0 ～ 800.0
220V type：360.0V
380V type：750.0V
0.1%
750.0V
○
FD06
FD.07
Auto start
function
0：Disabled
1：Enabled
1
0
○
FD07
FD.08
Auto start
delay time
0.0s ～ 100.0s
0.1s
10.0s
○
FD08
FD.09
MPPT Default
value adjusting
range
0.0V ～ 100.0V
0.1V
30.0V
○
FD09
