SAJ R5-3K-T2-15 - Page 32

R5 Series
- 31 -
Figure 5.2 Electrical interface of R5-13K/15K-T2
Figure 5.3 Electrical interface of R5-17K/20K-T2
Code
Name
A
DC Switch
B
Decompression Valves
C
DC Input
D
RS232 Communication (GPRS/ Wi-Fi /4G)
E
RS485 Communication
F
Ground Connection
G
AC Output
Table 5.2 Specifications for interface
