SAJ R5-3K-T2-15 - Chapter 7 Fault Code and Troubleshooting

R5 Series
- 49 -
Chapter 7 Fault Code and Troubleshooting
Error Code
Explanation
01
Relay Error Master
02
Storer Error Master
03
High Temperature Master
04
Low Temperature Master
05
Interior Communication Error Master
06
GFCI Devices Error Master
07
DCI Devices Error Master
08
Current Sensor Error Master
09/11/13
L1/L2/L3 Over Voltage Master
10/12/14
L1/L2L3 Low Voltage Master
15/16/17
L1/L2/L3 High Average Voltage of 10 minutes Master
18/20/22
L1/L2/L3 Over Frequency Master
19/21/23
L1/L2/L3 Low Frequency Master
24/25/26
L1/L2/L3 Grid Lost Error Master
27
GFCI Error Master
28/29/30
L1/L2/L3 DCI Error Master
31
Insulation Error Master
32
Unbalanced Bus Voltage Master
33
Over Bus Voltage Master
34
Under Bus Voltage Master
35/36/37
L1/L2/L3 Overcurrent Master
38
Bus Hardware Overvoltage Master
39/40
PV1/PV2 Hardware Overcurrent Master
41/42/43
L1/L2/L3 Hardware Overcurrent Master
45/46/47/48
Fan 1/2/3/4 Error Master
49
Loss of communication between Power Meter and Control
