R5 Series
- 45 -
4. Click “Event info”
Time of the events, events sequence number (referring to fault codes details in
Chapter 7 Fault Codes and Common Troubleshooting) and events content of the
faults of the inverter could be checked.
Device info
Bluetooth：R5-4K-T2:00001
R5T2043G1815E00001
Datetime：2018-11-10 18：16：00
No：Err73
Content：XXXX
2
Datetime：2018-11-09 18：16：00
No：Err73
Content：XXXX
1
Basic info
Running info Power info
Event info
Fig. 6.6 Events information
Connecting way 2 — Wi-Fi connection
After installing the eSolar WiFi module, the mobile phone could be directly
connected with the inverter via Wi-Fi.
Figure 6.7 Wi-Fi connection schematic diagram
