P3 V/F Control Parameters
Function
Code
Parameter
Name
Setting Range Default Property
P3-00 VF curve setting
0: Linear V/F
1: Multi-point V/F
2: Square V/F
3: 1.2 power V/F
4: 1.4 power V/F
6: 1.6 power V/F
8: 1.8 power V/F
9: Reserved
10: V/F complete
separation
11: V/F half separation
0 ★
P3-01 Torque boost
0.0%: (Automatic
torque boost)
0.1% ～ 30.0%
Model
dependent
☆
P3-02
Cut-o󽗈 frequency of torque
boost
0.00Hz ～ maximum
frequency
50.00Hz ★
P3-03 Multi-point V/F frequency 1 0.00Hz ～ P3-05 0.00Hz ★
P3-04 Multi-point V/F voltage 1 0.0% ～ 100.0% 0.0% ★
P3-05 Multi-point V/F frequency 2 P3-03 ～ P3-07 0.00Hz ★
P3-06 Multi-point V/F voltage 2 0.0% ～ 100.0% 0.0% ★
P3-07 Multi-point V/F frequency 3
P3-05 ～ rated motor
frequency (P1-04)
0.00Hz ★
P3-08 Multi-point V/F voltage 3 0.0% ～ 100.0% 0.0% ★
P3-09 V/F slip compensation gain 0.0% ～ 200.0% 0.0% ☆
P3-10 VF over-excitation gain 0 ～ 200 64 ☆
P3-11
VF oscillation suppression
gain
0 ～ 100
Model
dependent
☆
