27
P5 Output Terminals
Function
Code
Parameter
Name
Setting Range Default Property
P5-00
FM terminal
output mode
0: Pulse output (FMP)
1: Switch signal output (FMR)
0 ☆
P5-01
FMR output
function
selection
0: No output
1: AC drive running
2: Fault output (stop)
3: Frequency-level detection FDT1
output
4: Frequency reached
5: Zero-speed running (no output at
stop)
6: Motor overload pre-warning
7: AC drive overload pre-warning
8: Set count value reached
9: Designated count value reached
10: Length reached
11: PLC cycle complete
12: Accumulative running time
reached
13: Frequency limited
14: Torque limited
15: Ready for RUN
16: AI1 > AI2
17: Frequency upper limit reached
18: Frequency lower limit reached
(operation related)
19: Undervoltage state output
20: Communication setting
2 ☆
6.1 Brief introduction of function code
