2.12Weeklyscheduler
Number Function
Selected event (light color).
On/o indicator for selected event (green strip – event is on).
New mode. The mode with a green strip will be set as current on oc-
currence of selected event.
Active weekdays (green strips); inactive weekdays (gray strips).
Event time (24h format).
I1
I5
I2
I3
I4
Number Function
Event scrolls (10 weekly events available).
Select event.
Event on/o switch.
Buttons to select mode. This mode will be activated on occurrence
of selected event.
Buttons to select active weekdays for selected event.
Dials to set event hour and minute.
B1
B2
B3
B4
I1
B5
B3
I2
B1
B2
I2
B1
B4
I3
I5
B6
B6
I3
B5
B6
