2.13Holidayscheduler
Number Function
Selected event (light color).
On/o indicator for selected event (green strip – event is on).
Selected mode. The mode with a green strip will be set as current on
occurrence of selected event.
Day and time to start selected event. Selected mode will be set as
current.
Day and time to end selected event. Previous mode will be reset as
current.
I1
I5
I2
I3
I4
Number Function
Event scrolls (10 holiday events available).
Select event.
Event on/o switch.
Buttons to select mode. This mode will be activated on occurrence
of selected event.
Dials to set event starting hour and minute.
Dials to set event ending and minute.
B1
B2
B3
B4
I1
B5
B1
B2
I2
B1
I5
B6
B6
B5
B6
I4
B5
I3
B4
