RT300RF INSTRUCTION MANUAL
15
USER INTERFACE AND CONTROLS
The status and operation of the RT300RF is clearly shown on the large backlit
Liquid Crystal Display (LCD).
This display allows the user a clear indication
of the current room temperature, and the
status of the heating system.
There are few user controls for the RT300RF,
making this thermostat very easy to operate.
These controls are shown below, along with
a description of each of their functions.
USER CONTROL FUNCTION SUMMARY
Key / Operation Symbol Functions
UP key Increases the selected setting
DOWN key Decreases the selected setting
BACKLIGHT / Manually turns on the LCD backlight
FROST key for 5 seconds, or activates /
deactivates Frost Protection
RESET button Resets the programmable thermostat
to default (original factory) settings
Salus RT300RF Manual 002_89 22/07/2013 09:19 Page 15
