OPERATION
The ST620 is congured and adjusted by the use of an
innovative and stylish Touch Ring, and two touch sensitive
buttons. The Touch Ring surrounds the programmable
thermostat display, and is operated very easily by moving
your nger around the ring.
The backlit Liquid Crystal Display (LCD) gives a highly visible,
easily readable indication of the thermostat status.
ACCESSING THE MENUS
The Arrow key is not active when the ST620 is in NORMAL mode. To access
the Menu screens, press the OK key twice. The rst menu displayed is the
PROGRAMME menu:
Use the Touch Ring to scroll through the
Menus, and press the OK key to select
the menu you want to use:
You can scroll through the menus in
either direction (forwards or backwards)
depending on the direction you move
your nger around the Touch Ring. The
menus are displayed in the order shown
in the picture above.
Pressing and holding the Arrow key for 2 seconds will return the ST620 to NORMAL mode.
The programmable thermostat will also return to NORMAL mode after 10 seconds if no Key is pressed
or if no movement is detected on the Touch Ring.
ST620 INSTRUCTION MANUAL10
