The tables below outline power, electricity consumption and cable sections for both
230 V and 400 V. Using the information contained in the tables it is possible to cal-
culate cable sections in line with the EN 60204-1 regulation.
MODEL
20
Module
30
Module
PIZZA
Module
Steam
generator
Proofer
POWER
(kW)
E 7.8 9.8 9.8 1.4 2.2
ED 13 16.3 -- 2.5 --
EM 4.9 -- 6.2 1.4 1.1
EMD 9.1 -- 11.5 2.5 2.2
NXE 9.4 12.3 12.3 1.4 2.2
NXD 17.3 -- -- 2.5 --
NXM 6.6 8.2 8.2 1.4 1.1
LXP 11.4 -- -- 1.4 --
CON-
SUM.
(A)
230/400V
E 21.6/12.4 27.0/15.6 27.0/15.6 3.5/2.0 10/--
ED 34.7/19.3 43.5/24.1 -- 6.3/3.6 --
EM 13.6/7.8 -- 17.0/9.8 3.5/2.0 5/--
EMD 25.1/14.5 -- 31.7/18.3 6.3/3.6 10/--
NXE 25.9/14.9 34.1/18.6 34.1/18.6 3.5/2.0 10/--
NXD 45.9/26.4 -- -- 6.3/3.6 --
NXM 18.3/10.5 22.8/12.4 22.8/13.1 3.5/2.0 5/--
LXP 30.2/16.9 -- -- 3.5/2 --
The supply cable sections required by the EN 60204-1 regulation are calculated
using the total electricity consumption of the installed oven
For example, the total consumption of an “E” oven formed by 2 decks of 20 cm
height + 1 deck of 30 cm height with steam generator + 1 “Pizza” deck + 1 Proo-
fer, connected at 400 V.
“E”
OVEN
Quantity
Consumption
/ unit
Part
consumption
20 cm Module 2 12.4 24.8
30 cm Module 1 15.6 15.6
PIZZA Module 1 15.6 15.6
Steam generator 1 2.0 2.0
Proofer 1 10 10
Total consumption
68 A
