-79-
salva
E N G L I S H
11. Chimney
The steam outlet chimney should be installed by authorized
professionals according to local regulations.
The location for connection to the chimney is shown in the
following table:
Fundamental aspects:
• The chimney should preferable be insulated along its
length and not in contact with combustible materials
(such as wooden beams or ceilings).
• Sections should not be horizontal, but should instead
have a slope of at least 10º without bends or elbows
of radius less than twice the tube diameter.
• The chimney should incorporate a system for preven-
ting backflow of condensates.
• It is recommended that the chimney used be insulated
and of interior diameter 200 mm.
•
The oven steam output manifold must not be coupled
to the oven chimney in order to prevent excessive draft
which may affect the result of the baking.
mm 352,5 73 88
