Linkage (1) allows mounting mower on tractor's 3-point linkage. Drive from tractor's PTO is
transmitted by belt gear (3) onto LiteCUT cutter bar (4). Hydraulic lifting cylinder (2) fed from the tractor
external hydraulics is used to adjust the mower to working position. 3-point linkage frame (7), onto
which spring suspended cutter bar is set. The frame has also swath guides (5), which are standard-
delivered, optional disc type guides (7) and protective guard (6).
3.3. Standard equipment and spare parts
Mowers are sold with the following standard equipment:
❑ warranty card,
❑ operator's manual with spare part list and declaration of conformity,
❑ cutting knives: extra set,
❑ knife mounting lever,
❑ PTO shaft with overrunning clutch,
❑ spray paint (150 ml).
Optional equipment (on extra charge):
❑ warning triangle,
❑ topping skids,
❑ double rubber guide.
NOTICE:
Optional extra equipment should be ordered separately.
Tab. 3. Recommended PTO shaft
NOTICE:
Lubricate the PTO shaft with high quality multi-purpose grease every 50 shaft operating
hours (Fig. 3). If access holes are accessible, lubricate fittings through access holes.
