Operator’s manual
Bale wrapper
Spin
- 9 -
1. Refer to the operating manual
before performing this action
2. Turn off the engine and
remove the ignition key
before servicing or repairs
3. Do not approach the lifting
arm’s strands during the
wrapping machine’s
operation
WARNING! ROTATING ELEMENTS
4. Do not open or remove the
safety covers during machine
operation
5. Dangerous location 6. Warning on the threat caused
by rotating elements of the
working machine
KEEP A DISTANCE OF ST LEAST 3'
3" FROM THE OPERATING
MACHINE
7. Proper rotation direction of
the working elements
8. Do not approach the working
machine
9. Proper location of the bale
counter sensor below the
magnet
10. Film movement diagram 11. CE marking
